Summary of Contents for ROBINHOOD HED604FKG
- Page 1 Issue 2 Description: Robinhood Ceramic Cooktop 60cm Model Numbers: HED604FKG...
-
Page 2: Warning And Safety Information
Warning and safety information This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. - Page 3 Installation - continued Built in induction cooktop cutout dimensions. HED604FKG A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm) Installing the foam gasket Before inserting the appliance into the opening in the kitchen benchtop, the supplied foam gasket must be attached to the lower side of the glass ceramic (glass) cooktop between the benchtop and cooktop.
- Page 4 Installation - continued Installation procedure. Worktop must be placed absolutely horizontal. • Suitably protect the edges of the cut aperture. • Connect the cooktop to the mains power supply (see instructions for the connection of the cooktop to the mains power supply).
- Page 5 Installation - continued Technical information Type HED604FKG Width 580mm Rated voltage 220-240 V~ or 380-415 V 2N~, 50/60 Hz Type of switch Knobs Cooking zones ( Ømm, kW ) Forward left 230, 2.2 Rear left 165, 1.2 Rear right 200, 1.8 Forward right 165, 1.2...
- Page 6 Installation - continued Important warnings regarding the glass ceramic cooktop • Cooking zone reaches the selected power level or temperature very quickly; however, the area surrounding the cooking zones remains relatively cool. • The cooktop is resistant to temperature changes. •...
- Page 7 Installation - continued Energy saving tips When buying cookware be careful in selecting size: pot diameter usually refers to the top edge of the dish, which is often larger than the dish bottom. Use such dish size to accommodate the quantity of food to be prepared.
- Page 8 Instructions for use and maintenance Ceramic Glass Cooktop Hi-light element rear left Hi-light double element front left Hi-light element front right Hi-light element rear right Control knobs layout 1. Cooking zone indicator of rear left 2. Cooking zone indicator of front left 3.
-
Page 9: Cleaning And Maintenance
Cleaning & maintenance Cleaning and maintenance of ceramic glass cooktop Ceramic glass cooktop should be cleaned only when completely cooled down, preferably after each use, otherwise even the slightest stains remaining after cooking may burn into the cooktop surface with each following use. For regular maintenance of ceramic-glass cooktop use special cleansing agents, produced in such way to create protective film upon the surface. - Page 10 Important information The appliance may be built-in and connected to the power supply only by a qualified technician. Particular areas of the cooktop surface (adjacent to the hotplates) are hot during operation. Hot oil ignites readily, so be sure have the preparation of such food (fries) under constant control. Hotplates may not be left in operation empty, without any dishes on top.
- Page 11 The product was used outdoors. 2. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. 3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
- Page 12 The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (Monaco) Limited warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers - 24 months from date of original purchase for domestic use.
