- Page 1 Installation and Operating Instructions Issue: 1 Description: ROBINHOOD FREESTANDING OVEN GAS COOKTOP 60CM Model Numbers: RHFS609GX Actual product may vary from above picture...
-
Page 2: Table Of Contents
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions..........................3 Product Information ............................. -
Page 3: Important Safety Instructions
Important Safety Instructions Please read these safety instructions carefully. Installation and repair should always be performed by an authorised service. The manufacturer and supplier shall not be held responsible for operations performed by unauthorized persons. The oven should be used according to the operating instructions. Keep children below the age of 8 and pets away whilst operating. - Page 4 Important Safety Instructions 44. Food can spill when foot of oven is dismantled or gets broken, be careful. It may cause personal injuries. 45. During usage, the internal and external surfaces of the oven get hot. As you open the oven door, step back to avoid the hot vapour coming out from the interior.
- Page 5 Important Safety Instructions 22. WARNING: in order to prevent tipping of the appliance, this stabilizing means must be installed. Before using the appliance, in order to ensure safe use, be sure to fix the appliance to the wall using the chain and hooked screw supplied.
- Page 6 Important Safety Instructions Gas Safety This appliance is not connected to burning products evacuation apparatus. This appliance must be connected and installed according to the installation regulations in force. Conditions regarding ventilation must be considered. When a gas cooking appliance is used; humidity, heat and burning products are generated in the room. First of all, make sure the kitchen is well ventilated when operating the appliance and maintain natural ventilation openings or install mechanical ventilation equipment.
-
Page 7: Product Information
Product Information 1. Thermostat setting 6. Handle 11. Large burner 2. Oven setting 7. Plastic leg 12. Middle burner 3. Cooker section control switches 8. Lower cabinet door 13. Auxiliary burner 9. Lamp 4. Push button lighter 14. Wok burner 5. -
Page 8: Technical Data
Technical Data Specifications 60x60 Outer width 598 mm Outer depth 610 mm Outer height 860 mm Lamp power 15-25 W Bottom heating element 1200 W Top heating element 1000 W Grill heating element 2000 W Turbo heating element 2200 W Supply voltage 220-240V AC, 50 Hz Burner... -
Page 9: Accessories
Accessories Deep tray Used for pastry, big roasts, watery foods. It can also be used as oil collecting container if you roast directly on grill with cake, frozen foods and meat dishes. Tray / Glass tray Used for pastry (cookie, biscuit etc.), frozen foods. -
Page 10: Installation Instructions
Installation Instructions Electrical Connection Your oven requires 16 or 32 Ampere fuse according to the appliance’s power. If necessary, installation by a qualified electrician is recommended. Your oven is adjusted in compliance with 220-240V AC/380-415V AC 50/60Hz. electric supply. If the mains are different from this specified value, contact your authorized service. - Page 11 Installation Instructions For LPG Connection For LPG (cylinder) connection, affix a metal clamp on the hose coming from LPG cylinder. Affix an edge of the hose on hose inlet connector behind the appliance by pushing to end through heating the hose in boiled water. Afterward, bring the clamp towards end section of the hose and tighten it with screwdriver.
- Page 12 Installation Instructions Changing the Nozzle Use a screwdriver to remove and install the nozzle as in Figure 3. Remove the nozzle (figure 4) from the burner with nozzle driver and install a new nozzle (Figure 5). Figure 3 Figure 5 Figure 4 Ventilation of Room This product requires adequate ventilation.
- Page 13 Installation Instructions Check that the appliance has been properly connected to the power supply. If the electrical installation is not suitable, call an electrician and plumber to arrange the utilities as necessary. The manufacturer and supplier shall not be held responsible for damages caused by operations performed by unauthorized persons. WARNING: It is customer's responsibility to prepare the location the product shall be placed on and also to have the electrical installation prepared.
- Page 14 Installation Instructions Attaching the Feet Screw the feet into the bottom four corners of the oven. You can balance your oven by turning the screwed feet according to the surface type you are using. Figure 7 Figure 8 Figure 9 Chain Lashing Illustration In order to ensure safe use before using the appliance, be sure to fix the appliance to the wall using the chain and hooked screw supplied.
-
Page 15: Operating Instructions
Operating Instructions Controls Thermostat Front left cooktop Function selection button Front right cooktop Mechanical timer Rear right cooktop Rear left cooktop WARNING: The control panel above is only for illustration purposes. Consider the control panel on your device. Thermostat: Used for determining the cooking temperature of the dish to be cooked in the oven. - Page 16 Operating Instructions Using the Grill When grilling on the top rack, ensure that the food does not touch the grill. Place food in the center of the grill for best grilling results. To Start the Grill • Set the function dial to ‘Grill’. •...
- Page 17 Operating Instructions Pot Sizes 60*60 Small burner 12-18 cm Normal burner 18-20 cm Big burner 22-26 cm WOK burner 24-26 cm Incorrect Incorrect Incorrect Correct...
- Page 18 Operating Instructions Function Dial This is used for determining the cooking function to be used. The cooking functions are described below. All cooking functions may not be available in all models. Roast chicken Lower and upper heating Fan force elements Lower-upper heating element Lamp and fan...
-
Page 19: Maintenance And Cleaning
Maintenance and Cleaning WARNING: Disconnect the appliance from the electrical supply before performing any maintenance or cleaning. While the oven is operating or shortly after it starts operating, it is extremely hot. Avoid touching the heating elements. Do not use harsh cleaners such as hard wire brushes, abrasive cleaners or detergents. Use a soft, damp, soapy cloth to clean the interior of the oven. - Page 20 Maintenance and Cleaning Installation of Oven Door Figure 18.1 Figure 18.2 Figure 19.1 Figure 19.2 Completely open the Bring the hinge lock Afterwards, close To remove the oven oven door by pulling it to the widest angle the oven door as to door, pull it upwards towards yourself.
- Page 21 Maintenance and Cleaning Cleaning And Maintenance of the Oven’s Front Door Glass Remove the profile by pressing the plastic latches on both left and right sides as shown in figure 20 and pulling the profile towards yourself as shown in figure 21. Then remove the inner-glass as shown in figure 22. If required, the middle glass can be removed in the same way.
-
Page 22: Changing The Lamp
Changing the Lamp WARNING: Disconnect the appliance from the power supply and ensure that it is cold before changing the lamp. • Unscrew the glass protective cover. • Remove the lamp by turning it; install a new lamp with the same specifications. •... -
Page 23: Troubleshooting
Troubleshooting You may solve the problems you may encounter with your product by checking the following points before calling the technical service. Problem Possible Cause What to Do Power supply not available. Check for power supply. Check if main gas valve is open. Check if gas pipe is bent or kinked. -
Page 24: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: ... -
Page 25: Warranty Certificate (Australia)
The product was used outdoors. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
