INSTALLATION & MAINTENANCE GUIDE
AMP
Low Voltage Landscape Lighting
®
AMP
Stem with Integrated Hub
®
AAL-1024-0-B-BZ
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
w w w. a m p l i g h t i n g . c o m

Advertisement

loading
Need help?

Need help?

Do you have a question about the AAL-1024-0-B-BZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMP Lighting AAL-1024-0-B-BZ

  • Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® Stem with Integrated Hub ® AAL-1024-0-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
  • Page 2: Important Safety Instructions

    INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
  • Page 3 Package Contents A. (1) Fixture Body B. (1) Integrated Hub Top Product Dimensions 4” 22” 1” 2.83” There are two types of mounts that are sold separately for this fixture, the Stake Mount and Surface Mount. customersupport@amplighting.com • 813.978.3900 –3–...
  • Page 4: Wire Connection

    INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Option 1: Stake Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Stake Mount Main Supply Wire Main Supply Wire Continuation Insert the main supply wire continuation (if needed) and the main supply wire up through the bottom of the stake mount and strip the ends of both sets of supply wires.
  • Page 5 INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Install Stake Mount Clear away an area in the ground at the wireway slot on top of the stake. Lay the supply Stake Mount Wireway Slot wires into the wireway slot and screw the stake mount on to the stake.
  • Page 6 INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Option 2: Surface Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Surface Mount Main Supply Wire Main Supply Wire Continuation Insert the main supply wire continuation (if needed) and the main supply wire up through the bottom of the surface mount and strip the ends of both sets of supply wires.
  • Page 7: Bulb Installation

    INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Bulb Installation Remove Stem Top Twist the stem top counter- clock- wise and remove it from the stem. Stem Top Stem Install Bulb Insert the bulb with the correct watt- age and type marked on the fixture Bulb label and push firmly into place.
  • Page 8 INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Install Stem Top to Stem Place the stem top over the bulb and twist it clockwise onto the stem. Stem Top Stem Install Cast Brass Hat to Stem (Option A) Thread the hat of your choice Hat of your choice onto the stem top.
  • Page 9 INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Install Spun Brass Hat to Stem (Option B) Finial Hat of your choice Place the hat of your choice onto the stem top and secure it with the finial. Hand tighten until snug. Shield customersupport@amplighting.com •...
  • Page 10 INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ Install/Replace Bulb Remove the hat and stem top to expose the bulb and replace it with the correct wattage and type marked on the fixture label. Then, reinstall the stem top and hat. IMPORTANT: Bulbs must be protected from moisture and dust at all times.
  • Page 11 INSTALLATION & MAINTENANCE GUIDE Stem with Integrated Hub Top ® ASM-2408-0-B-BZ customersupport@amplighting.com • 813.978.3900 –11–...
  • Page 12 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-ASM-2408-0-BBZ-ver1.pdf...
