- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® ONE ControlPro 200 LED Downlight ® AAL-1813IR-40-BBZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
-
Page 2: Important Safety Instructions
INSTALLATION & MAINTENANCE GUIDE ONE ControlPro 200 LED Downlight ® AAL-1813IR-40-BBZ Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Package Contents A. (1) Fixture B. (1) 35 Optic * Ships with a 60°optic installed. Parts Required (sold separately) A. (1) ONE Design-Master Remote Control Product Dimensions 6 5/8” 4.68” 4 1/8” Install Fixture Determine the desired location Foot Washer (not supplied) for the fixture.
- Page 4 INSTALLATION & MAINTENANCE GUIDE ONE ControlPro 200 LED Downlight ® AAL-1813IR-40-BBZ Wire Connections Strip both leads from the luminaire pigtail. Using two wire connectors (sold separately), connect the leads from the luminaire to the main supply cable leads. Pigtail Wire Connectors Main Supply Cable Adjust Glare Guard Direction Unlock the knob and rotate...
- Page 5 Install/Replace Optic Remove Glare Guard Loosen the set screw and remove the glare guard from the fixture. Fixture Set Screw Glare Guard Install Fixture to Stake Loosen the fixture lens and remove it from the fixture. Fixture Fixture Lens customersupport@amplighting.com • 813.978.3900 –5–...
- Page 6 INSTALLATION & MAINTENANCE GUIDE ONE ControlPro 200 LED Downlight ® AAL-1813IR-40-BBZ Replace Optic Loosen the screws, and remove the optic from the fixture. Fixture Install the new optic in the fixture LED Board and reverse Step 6 - Step 4. Confirm the optic is properly aligned over the LED board before tightening down.
- Page 7 customersupport@amplighting.com • 813.978.3900 –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-AAL-1813IR-40-BBZ.ver1...
