Remote Control Alarm & Remote Engine Starting System
CONGRATULATIONS on your choice of a Super Rage™ Alarm & Remote Engine Starter by Crimestopper
Security Products Inc. This booklet contains the information necessary for operating your system. If any
questions arise, contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Power,
Ground, Lights, Siren, etc.
-OPTIONAL: Optional features are connected only if desired or agreed upon by the installing dealer i.e. Door
Locks, Horn Honk, Dome light illumination, Starter Kill, L.E.D., Trunk Pop, etc. These features may require
additional parts and labor charges. Consult with your installer about these features before installation.
CONTACT INFORMATION:
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER
SECURITY PRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063
CS-2011RS Series IV
Super Rage™
OPERATION INSTRUCTIONS
INTRODUCTION
REV. A 9.2003
This device complies with FCC Rules part 15. Operation is subject
to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference
caused
by
equipment. Such modification could void the user's authority to
operate the equipment.
unauthorized
modification
to
this
Advertisement
Table of Contents
Related Manuals for CrimeStopper Super Rage CS-2011RS IV Series
Summary of Contents for CrimeStopper Super Rage CS-2011RS IV Series
- Page 1 CONGRATULATIONS on your choice of a Super Rage™ Alarm & Remote Engine Starter by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. *IMPORTANT INFORMATION: Primary and Optional Features -PRIMARY: These are features that must be connected in order for the system to operate properly i.e.
-
Page 2: Table Of Contents
Troubleshooting: “Before you call section”……………………………………………………………………..….15 OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in good running order. -
Page 3: Operating Instructions - Alarm
If a door is left open after an intrusion then the unit will cycle a maximum of 5 minutes and continue to protect the other un-tampered or unopened zones. ARM/ LOCK TRUNK CS-2011RS TRANSMITTER BUTTONS DISARM UNLOCK 2-CAR PG. 14... - Page 4 OPERATING INSTRUCTIONS - ALARM Prior intrusion Alert This system will notify you if the alarm was tripped while you where away. Upon disarming, the two normal disarm chirps will be heard then the system will emit 4 additional siren chirps. Check your vehicle for any signs of a break in or tampering.
- Page 5 OPERATING INSTRUCTIONS - ALARM Remote AUX. Output 2 (Optional) This system contains a second auxiliary output to activate other accessories or devices. To activate the systems’ Second Auxiliary Output, press and hold Button #3 (Trunk Symbol) on the transmitter for more than 2 seconds.
-
Page 6: Alarm
The CS-2011RS system includes disarm diagnostics, through the RED LED light, that will help in determining what caused the last trigger of the alarm system. This is a valuable tool in determining how the vehicle was tampered with or if there is a false alarm problem in which case you can make the necessary adjustments to correct the problem. - Page 7 REMOTE ENGINE CONTROL REMOTE ENGINE STARTING - SUCCESSFUL START DIAGRAM: SOLID FLASH 1X AFTER START STARTER SEC. THEN SOLID REMOTE ENGINE STARTING - UNSUCCESSFUL START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 and 3 time.
- Page 8 ENTERING YOUR REMOTE STARTED VEHICLE: 1) With engine running, Remote Unlock/Disarm system (If armed) or open door with key. 2) Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset) 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed.
- Page 9 INFINITY RUN MODE This mode allows the vehicle’s engine to remain running INDEFINITELY. This mode can be beneficial to law enforcement vehicles or commercial vehicles that need to remain running unattended for long periods of time. INFINITY RUN MODE – EXITING THE VEHICLE: 1) Follow steps on the last page for “IDLE DOWN MODE - EXITING THE VEHICLE”, except press the remote start button TWO times at STEP #1.
- Page 10 TIMED SELF START MODE This mode allows the vehicle to be programmed to self-start every 4 hours and run for the programmed run time. This can be helpful during extremely cold conditions where engine fluid freeze-up is a concern. THE VEHICLE MUST BE OUTDOORS OR IN A WELL VENILATED AREA.
-
Page 11: Optional Turbo Timer Mode
OPTIONAL TURBO TIMER MODE: IMPORTANT NOTE: This mode requires the use of an extra part called a momentary switch or button that is not included with the kit. Check with your installer about adding this feature. The optional Turbo Timer mode allows the your system to keep your vehicle running for 1 to 5 minutes [selectively] after you remove the key, exit the vehicle, and lock the doors remotely [if you own a Turbo or Turbo Diesel]. -
Page 12: Anti-Carjack Protection
REMOTE OPERATED CARJACK PROTECTION This feature provides Active Carjack protection through the remote control. When the Ignition is on (vehicle is running), press and hold the #1 LOCK Button and #3 TRUNK Button for 2 seconds. The parking lights will flash 2 times and the LED will begin to flash rapidly to confirm the beginning of a Carjack countdown. -
Page 13: Transmitter Programming
Note: Remotes Transmitters come pre-programmed from the Factory. When re-learning remotes or adding remotes, ALL your system’s remote codes must be learned at time of programming!! This system allow storage of up to 4 different remote codes in memory. 1. Open hood (ground the Blue hood pin wire if no hood pin is installed.) 2. -
Page 14: Vehicle Operation
2 VEHICLE OPERATION The CS-2011RS Series IV system can be used for 2 car operation. A single remote can control two independent vehicles with an identical systems installed. See diagram below on how to switch your remote to car 2 operation. Follow the “Transmitter Programming”... -
Page 15: Troubleshooting: "Before You Call Section
TROUBLESHOOTING: “BEFORE YOU CALL SECTION” Before calling your dealer or Crimestopper, read the following section for tips that may remedy or explain your problem. SYSTEM LED FLICKERS WHEN PRESSING REMOTE CONTROL BUTTONS: This is normal operation. There may be a slight flicker visible from the LED when pressing the remote as the system is authorizing the code from the remote control. - Page 16 ONLINE TECHNICAL SUPPORT Phone (800) 998-6880 www.crimestopper.com/techweb03.html FAX (805) 581-9500 © 2003 Crimestopper Security Products...
