CS-2014TW2 Super Page V™
2-Way AM/FM LCD Paging Alarm & Remote Engine Starting System
CONGRATULATIONS on your choice of the SuperPage V ™ by Crimestopper Security Products Inc. This booklet
contains the information necessary for operating your system. If any questions arise, contact your installation dealer or
Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These features must be connected in order for the system to operate properly i.e. Power, Ground, LED,
etc.
-OPTIONAL: Optional features are connected only if desired or agreed upon by the installing dealer i.e. Horn Honk,
Dome light illumination, Door Locks, Trunk Pop, etc. These features may require additional parts and labor charges.
Consult with your installer about these features BEFORE installation!
CONTACT INFORMATION:
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER
SECURITY PRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063
OPERATION INSTRUCTIONS
INTRODUCTION
REV. A1 02.01.2005
This device complies with FCC Rules part 15. Operation is subject
to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference
caused
by
equipment. Such modification could void the user's authority to
operate the equipment.
unauthorized
modification
to
this
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CrimeStopper Super Page V CS-2014TW2
Summary of Contents for CrimeStopper Super Page V CS-2014TW2
- Page 1 2-Way AM/FM LCD Paging Alarm & Remote Engine Starting System OPERATION INSTRUCTIONS CONGRATULATIONS on your choice of the SuperPage V ™ by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.
-
Page 2: Table Of Contents
Low Battery Warning – LCD Remote / Setting Clock – LCD Remote……………………………….….……..19 OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be l i able for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in good running order. -
Page 3: Transceiver / Pager-Remote
TRANSCEIVER / PAGER-REMOTE PAGER / REMOTE TRANSCEIVER: The hand-held remote transceiver is used to send and receive information from the vehicle. The Control Module transmits High Frequency AM/FM signals from the vehicle to your over long distances. Your range will vary depending on location, terrain, and local RF noise/interference. -
Page 4: Remote Start
The CS-416TW 1-Way sidekick remote adds flexibility to your CS-2014TW2. You can have the convenience of operating your system without needing to carry the larger pager remote. The Sidekick remote has less range and offers all of the same operation features except for page-back confirmation. -
Page 5: Operating Instructions - Alarm
OPERATING INSTRUCTIONS - ALARM Active Arming / Locking: Press button #1 (Lock symbol) on the transceiver. The System will arm emit one siren chirp, one light flash, and the LED will begin to flash. Power locks will lock (if equipped). Starter disable circuit will turn on. -
Page 6: Silent Arm
OPERATING INSTRUCTIONS - ALARM Disarming While Tripped (Triggered): Disarming the System while it is triggering requires TWO presses of the #2 Unlock Button. The first press of Button #2 Resets the alarm cycle only (system still armed) while a second press will disarm/unlock the system. Selective Silent Arming/Disarming: To Arm or Disarm the system without siren chirps, press and release both Buttons #2 (Unlock) and #4 (Start) at the same time. - Page 7 OPERATING INSTRUCTIONS - ALARM Pre-Warning Shock Protection The Pre-warning (warn-away) feature will activate when a low-level shock or vibration detected by the system’s shock sensor. The alarm will chirp the siren 5 times and flash the lights once to help deter any further tampering with the vehicle. The pager/remote will vibrate and beep (1).
-
Page 8: Valet Mode
OPERATING INSTRUCTIONS - ALARM Emergency Override (Disarm) If you have lost the transmitter or it stops working for any reason and the Alarm is armed, you will have to disarm the system manually. Open the door with the key [alarm will sound], turn the ignition on, and press the override/program button for about 5 seconds. -
Page 9: Remote Engine Control
REMOTE ENGINE STARTING - SUCCESSFUL START 1) Press remote start button on the remote transmitter. System will chirp 3 times for audible confirmation. (Chirps can be programmed on or off-See installation manual.) 2) Parking lights flash once, then turn on solid, Ignition/Accessory circuits turn on. 3) After a few seconds, Starter Motor engages, Parking lights and Accessory circuits turn off while cranking. - Page 10 UNSUCCESSFUL REMOTE START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 time of up to13 seconds maximum. This should provide ample cranking time for difficult starts, but is limited to 13 seconds to help prevent damage to the starter from over cranking.
- Page 11 IDLE DOWN MODE (TAKE-OVER OPERATION) This mode allows the unit to take over operation of your idling, parked vehicle while the ignition key is removed and you exit the vehicle. The vehicle is put into a remote running condition before you exit and it will remain running for the programmed run time, until you return, or until the remote start button is pressed.
- Page 12 REMOTE ENGINE CONTROL TIMED SELF START MODE This mode allows the vehicle to be programmed to self-start every 4 hours and run for the programmed run time. This can be helpful during extremely cold conditions where engine or fluid freeze-up is a concern. !!THE VEHICLE MUST BE OUTDOORS OR IN A WELL VENILATED AREA!! TIMED SELF-START MODE –...
-
Page 13: Anti-Carjack Protection
ANTI CARJACK PROTECTION REMOTE OPERATED CARJACK PROTECTION This feature provides Active Carjack protection through the remote control. When the Ignition is on (vehicle is running), press and hold the #1 LOCK Button and #3 TRUNK Button for 2 seconds. The parking lights will flash 2 times and the LED will begin to flash rapidly to confirm the beginning of a Carjack countdown. -
Page 14: Led Diagnostics
The CS-2014FM system includes disarm diagnostics, through the RED LED light, that will help in determining what caused the last trigger of the alarm system. This is a valuable tool in determining how the vehicle was tampered with or if there is a false alarm problem in which case you can make the necessary adjustments to correct the problem. - Page 15 TRANSCEIVER / REMOTE CONTROL PROGRAMMING WAIT FOR (BLUE WIRE GROUNDED) 4 FLASHES PRESS 4X's 2-WAY SYSTEMS & "SideKick" REMOTES FLASH 2, 3, or 4 X's LOCK & COMPLETE UNLOCK PRESS TOGETHER...
-
Page 16: Vehicle Operation
2 VEHICLE CONTROL Your CS-2014FM remotes have the ability to control a second vehicle with a Crimestopper CS-2014FM system installed. To set up the 2-Vehicle operation you must first program your remotes to Vehicle #2. Follow the “Transmitter Programming” steps (Pg. 14) at the second vehicle and learn YOUR remote, along with vehicle #2’s existing remotes. -
Page 17: Troubleshooting / Faq Section
TROUBLESHOOTING FAQ’s: “BEFORE YOU CALL SECTION” Before calling your dealer or Crimestopper, read the following section for tips that may remedy or explain your problem. RANGE QUESTIONS (2-Way Pager/Remote): Your CS-2014FM system uses FM High-Frequency signals to send/receive data between the pager and the vehicle and from the vehicle to the remote for state-of-the-art operation. - Page 18 SYSTEM IS NOT SUCCESSFUL AT REMOTE STARTING DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start, or it may not successfully start the vehicle after 3 attempts. During these conditions, the vehicle may not properly start even using the key;...
-
Page 19: Low Battery Warning - Lcd Remote / Setting Clock - Lcd Remote
LOW BATTERY WARNING - LCD REMOTE Your 2-Way pager remote will warn you when the battery gets low. You will see a battery icon on the LCD screen when it is time to replace the AAA battery. To replace the battery: simply unlatch and slide open the battery door on the back of the 2-Way LCD remote. - Page 20 Crimestopper Security Products Inc. 1770 So. Tapo Street ONLINE TECHNICAL SUPPORT www.crimestopper.com/techweb03.html Simi Valley, CA 93063 (800) 998-6880 www.crimestopper.com email@crimestopper.com ©2005 Crimestopper Security Products...
