2-Way AM/FM Paging Remote Alarm, Keyless Entry System & Engine Starting
CONGRATULATIONS on your choice of a CS-2012TW1 Super Rage™ Alarm & Remote Engine Starter by
Crimestopper Security Products Inc. This booklet contains the information necessary for operating your
system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Power,
Ground, Flashing Lights, Siren, LED, etc.
-OPTIONAL: Optional features are connected only if desired or agreed upon by the installing dealer i.e. Door
Locks, Horn Honk, Dome light illumination, Trunk Pop, etc. These features may require additional parts and
labor charges. Consult with your installer about these features before installation.
CONTACT INFORMATION:
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER
SECURITY PRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063
CS-2012TW1
Super Rage™
System with 1-Way Sidekick Remote Control
OPERATING INSTRUCTIONS
REV. C 05.2005
This device complies with FCC Rules part 15. Operation is subject
to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference
caused
by
equipment. Such modification could void the user's authority to
operate the equipment.
unauthorized
modification
to
this

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Super Rage CS-2012TW1 and is the answer not in the manual?

Questions and answers

Summary of Contents for CrimeStopper Super Rage CS-2012TW1

  • Page 1 2-Way AM/FM Paging Remote Alarm, Keyless Entry System & Engine Starting System with 1-Way Sidekick Remote Control CONGRATULATIONS on your choice of a CS-2012TW1 Super Rage™ Alarm & Remote Engine Starter by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system.
  • Page 2: Table Of Contents

    OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in good running order.
  • Page 3: 2-Way Led Paging Remote

    PAGER / REMOTE TRANSCEIVER: The hand-held remote transceiver is used to send and receive information from the vehicle. The Control Module transmits confirmation signals from the vehicle to your pager. Your range will vary depending on location, terrain, and local RF noise/interference.
  • Page 4: 1-Way "Sidekick" Non-Paging Remote

    1-WAY “SIDEKICK” NON-PAGING REMOTE The 1-Way sidekick remote adds flexibility to your CS-2012TW1. You have the convenience of operating your system without needing to carry the pager remote. The “Sidekick” remote offers all of the same operation features remote, except the range is lower and it will not receive page-back confirmations from the vehicle.
  • Page 5: Paging Tones & Leds

    TURN OFF ENGINE #4 (Start) (From remote) DOOR VIOLATION HOOD/TRUNK VIOLATION SHOCK VIOLATION PRE-WARN IGNITION VIOLATION PAGING TONES & LEDs CS-2012TW1 PAGING LEDs Blue LED: Red LED: Door Trigger Remote Start, Ignition PAGE-BACK: ACTION BEEPS Press & Release 1X, then 1X Press &...
  • Page 6: Operating Instructions - Alarm

    OPERATING INSTRUCTIONS - ALARM Active Arming / Locking: Press and release button #1 (Lock symbol) on the transmitter. The system will arm and confirm with one siren chirp, one light flash, and the LED will begin to flash. Power locks will lock (if equipped). Starter disable circuit will turn on.
  • Page 7 Passive arming provides failsafe protection in case you forget to arm the system. Passive Locking: (Programmable) The CS-2012TW1 system can be programmed to passively lock the doors when the system passively arms. The default setting is OFF because passive locking increases the risk of locking the keys in the vehicle.
  • Page 8 OPERATING INSTRUCTIONS - ALARM Remote AUX. Output 2 (Optional) This system contains a second auxiliary output to activate other accessories or devices. To activate the systems’ Second Auxiliary Output, press and hold Button #3 (Trunk Symbol) on the transmitter for more than 2 seconds.
  • Page 9: Operating Instructions - Alarm

    Basic M.A.P. wiring information is provided in the installation manual. The CS-2012TW1 system includes disarm diagnostics, through the RED LED light, that will help in determining what caused the last trigger of the alarm system. This is a valuable tool in determining how the vehicle was tampered with or if there is a false alarm problem in which case you can make the necessary adjustments to correct the problem.
  • Page 10 REMOTE ENGINE CONTROL REMOTE ENGINE STARTING - SUCCESSFUL START DIAGRAM: SOLID FLASH 1X AFTER START STARTER SEC. THEN SOLID REMOTE ENGINE STARTING - UNSUCCESSFUL START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 and 3 time.
  • Page 11 REMOTE ENGINE CONTROL ENTERING YOUR REMOTE STARTED VEHICLE: 1) With engine running, Remote Unlock/Disarm system (If armed) or open door with key. 2) Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset) 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed.
  • Page 12 INFINITY RUN MODE This mode allows the vehicle’s engine to remain running INDEFINITELY. This mode can be beneficial to law enforcement vehicles or commercial vehicles that need to remain running unattended for long periods of time. INFINITY RUN MODE – EXITING THE VEHICLE: 1) Follow steps on the last page for “IDLE DOWN MODE - EXITING THE VEHICLE”, except press the remote start button TWO times at STEP #1.
  • Page 13 TIMED SELF START MODE This mode allows the vehicle to be programmed to self-start every 4 hours and run for the programmed run time. This can be helpful during extremely cold conditions where engine fluid freeze-up is a concern. THE VEHICLE MUST BE OUTDOORS OR IN A WELL VENILATED AREA.
  • Page 14: Optional Turbo Timer Mode

    OPTIONAL TURBO TIMER MODE: IMPORTANT NOTE: This mode requires the use of an extra part called a momentary switch or button that is not included with the kit. Check with your installer about adding this feature. The optional Turbo Timer mode allows the your system to keep your vehicle running for 1 to 5 minutes [selectively] after you remove the key, exit the vehicle, and lock the doors remotely [if you own a Turbo or Turbo Diesel].
  • Page 15: Anti-Carjack Protection

    REMOTE OPERATED CARJACK PROTECTION This feature provides Active Carjack protection through the remote control. When the Ignition is on (vehicle is running), press and hold the #1 LOCK Button and #3 TRUNK Button for 3 seconds. The parking lights will flash 2 times and the LED will begin to flash rapidly to confirm the beginning of a Carjack countdown.
  • Page 16: Transmitter Programming

    Note: Remotes Transmitters come pre-programmed from the Factory. When re-learning remotes or adding remotes, ALL your system’s remote codes must be learned at time of programming!! This system allows storage of up to 4 different remote codes in memory. 1. Open hood (ground the Blue hood pin wire if no hood pin is installed.) 2.
  • Page 17: Pager Remote Battery Replacement

    CS-2012TW1 PAGER (LOW BATTERY WARNING) The CS-2012TW1 Pager LED has a low battery warning system. When the battery voltage is low, the Orange & Green LEDs flash 6 times with any button that is pressed. We recommend replacing the battery for proper operation.
  • Page 18: Troubleshooting: "Before You Call Section

    3) This CS-2012TW1 system does NOT use “Paging” or “Cellular” antenna service. There are no monthly fees associated with its operation. The CS-2012TW1 unit in the vehicle sends a paging signal directly to your pager/remote from its own antenna mounted inside the vehicle.
  • Page 19 UNIT FLASHES THE LIGHTS ONCE AND WILL NOT ATTEMPT A REMOTE START: The system is in Valet mode. Check the systems LED light and if it is on solid Red LED (with doors closed) then the system is in VALET mode. To exit VALET, turn the Ignition on, press and hold valet/programming button for about 5 seconds until LED goes out.
  • Page 20 ONLINE TECHNICAL SUPPORT Phone (800) 998-6880 www.crimestopper.com/techweb03.html FAX (805) 581-9500 © 2005 Crimestopper Security Products...
