2-Way FM/FM Paging Remote Alarm, Keyless Entry System & Engine Starting
CONGRATULATIONS on your choice of a CS-2012DP-TW1 Super Rage™ Alarm & Remote Engine Starter
by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your
system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Power,
Ground, Flashing Lights, Siren, LED, etc.
-OPTIONAL: Optional features are connected only if desired or agreed upon by the installing dealer i.e. Door
Locks, Horn Honk, Dome light illumination, Trunk Pop, etc. These features may require additional parts and
labor charges. Consult with your installer about these features before installation.
CONTACT INFORMATION:
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER
SECURITY PRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063
CS-2012DPII-TW1
Super Rage™
System with 1-Way Sidekick Remote Control
OPERATING INSTRUCTIONS
REV. 06.30.2007
This device complies with FCC Rules part 15. Operation is subject
to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference
caused
by
equipment. Such modification could void the user's authority to
operate the equipment.
unauthorized
modification
to
this

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Super Rage CS-2012DPII-TW1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CrimeStopper Super Rage CS-2012DPII-TW1

  • Page 1 CONGRATULATIONS on your choice of a CS-2012DP-TW1 Super Rage™ Alarm & Remote Engine Starter by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.
  • Page 2: Table Of Contents

    OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in good running order.
  • Page 3: 2-Way Led Paging Remote

    PAGER / REMOTE TRANSCEIVER: The hand-held remote transceiver is used to send and receive information from the vehicle. The Control Module transmits confirmation signals from the vehicle to your pager. Your range will vary depending on location, terrain, and local RF noise/interference.
  • Page 4: 1-Way "Sidekick" Non-Paging Remote

    1-Way sidekick remote adds flexibility to your CS-2012DP-TW1. You can have the convenience of operating your system without needing to carry the larger pager remote. The Sidekick remote has less range and offers all of the same operation features except for page-back confirmation. See diagram below Sidekick...
  • Page 5: Paging Tones & Leds

    Yellow LED: Shock sensor, Trunk pop BUTTON FEATURE LOCK #1 (Lock) UNLOCK #2 (Unlock) AUX #1 #3 (Trunk) AUX #2 #2&3 AUX #3 #1&4 AUX #4 #3&4 PANIC #1 (Lock) REMOTE START #4 (Start) REQUEST ENGINE RUNNING CONFIRMATION TURN OFF ENGINE #4 (Start) (From remote) DOOR VIOLATION...
  • Page 6: Operating Instructions - Alarm

    OPERATING INSTRUCTIONS - ALARM Active Arming / Locking: Press and release button #1 (Lock symbol) on the transmitter. The system will arm and confirm with one siren chirp, one light flash, and the LED will begin to flash. Power locks will lock (if equipped). Starter disable circuit will turn on.
  • Page 7 OPERATING INSTRUCTIONS - ALARM Alarm Triggering An intrusion into the vehicle or hard impact to the body will sound the alarm and flash the lights for 20 Sec. After 20 Sec. the trigger cycle will automatically stop and alarm will remain armed to continue protecting the vehicle.
  • Page 8 OPERATING INSTRUCTIONS - ALARM Remote AUX. Output 2 (Optional) This system contains a second auxiliary output to activate other accessories or devices. To activate Output 2, press and hold Button 2 & 3. This is a momentary output that will stay active as long as the remote button is held down. Remote output #2 requires programming before operation.
  • Page 9: Led Diagnostics

    OPERATING INSTRUCTIONS - ALARM Optional M.A.P. (Mobile Accessories Protection) This system can be programmed to provide Crimestopper’s unique M.A.P. (Mobile Accessories Protection) feature that allows you to prevent unauthorized access of your vehicles Audio, Cellular, Navigation, or Entertainment systems. This feature is OPTIONAL and will requires extra parts and labor for installation. Consult your installation dealer about MAP before or during installation.
  • Page 10 REMOTE ENGINE CONTROL REMOTE ENGINE STARTING - SUCCESSFUL START DIAGRAM: SOLID FLASH 1X AFTER START STARTER SEC. THEN SOLID REMOTE ENGINE STARTING - UNSUCCESSFUL START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 and 3 time.
  • Page 11 REMOTE ENGINE CONTROL ENTERING YOUR REMOTE STARTED VEHICLE: 1) With engine running, Remote Unlock/Disarm system (If armed) or open door with key. 2) Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset) 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed.
  • Page 12 INFINITY RUN MODE This mode allows the vehicle’s engine to remain running INDEFINITELY. This mode can be beneficial to law enforcement vehicles or commercial vehicles that need to remain running unattended for long periods of time. INFINITY RUN MODE – EXITING THE VEHICLE: 1) Follow steps on the last page for “IDLE DOWN MODE - EXITING THE VEHICLE”, except press the remote start button TWO times at STEP #1.
  • Page 13: Remote Engine Control

    TIMED SELF START MODE This mode allows the vehicle to be programmed to self-start every 4 hours and run for the programmed run time. This can be helpful during extremely cold conditions where engine fluid freeze-up is a concern. THE VEHICLE MUST BE OUTDOORS OR IN A WELL VENILATED AREA.
  • Page 14: Optional Turbo Timer Mode

    OPTIONAL TURBO TIMER MODE: IMPORTANT NOTE: This mode requires the use of an extra part called a momentary switch or button that is not included with the kit. Check with your installer about adding this feature. The optional Turbo Timer mode allows the your system to keep your vehicle running for 1 to 5 minutes [selectively] after you remove the key, exit the vehicle, and lock the doors remotely [if you own a Turbo or Turbo Diesel].
  • Page 15: Anti-Carjack Protection

    REMOTE OPERATED CARJACK PROTECTION This feature provides Active Carjack protection through the remote control. When the Ignition is on (vehicle is running), press and hold the #1 LOCK Button and #3 TRUNK Button for 3 seconds. The parking lights will flash 2 times and the LED will begin to flash rapidly to confirm the beginning of a Carjack countdown.
  • Page 16: Transmitter Programming

    Note: Remotes Transmitters come pre-programmed from the Factory. When re-learning remotes or adding remotes, ALL your system’s remote codes must be learned at time of programming!! This system allows storage of up to 4 different remote codes in memory. 1. Turn key to the ON position. (Starting the vehicle is not necessary.) 2.
  • Page 17: Pager Remote Battery Replacement

    PAGER REMOTE BATTERY REPLACEMENT CS-2012DP-TW1 PAGER (LOW BATTERY WARNING) FLASH 6X The CS-2012DP-TW1 Pager LED has a low battery warning system. ORANGE When the battery voltage is low, the Orange & Green LEDs flash 6 times with any button that is pressed. We recommend replacing the GREEN battery for proper operation.
  • Page 18: Troubleshooting: "Before You Call Section

    TROUBLESHOOTING: “BEFORE YOU CALL SECTION” Before calling your dealer or Crimestopper, read the following for tips that may remedy the problem. RANGE QUESTIONS (2-Way Pager/Remote): Your CS-2012DP-TW1 system uses Am & FM High-Frequency signals to send/receive data between the pager and the vehicle and from the vehicle to the remote for state-of-the-art operation. 1) Under normal operation, the distance from the vehicle-paging-the-remote will be greater than that from the remote-to-the-vehicle.
  • Page 19 UNIT FLASHES THE LIGHTS ONCE AND WILL NOT ATTEMPT A REMOTE START: The system is in Valet mode. Check the systems LED light and if it is on solid Red LED (with doors closed) then the system is in VALET mode. To exit VALET, turn the Ignition on, press and hold valet/programming button for about 5 seconds until LED goes out.
  • Page 20 ONLINE TECHNICAL SUPPORT Phone (800) 998-6880 www.crimestopper.com FAX (805) 581-9500 © 2007 Crimestopper Security Products...
