802.11ax Access Point
User Manual
C
2. H
C
HAPTER
ARDWARE
OMPONENTS
2.1. Package Contents
Carefully remove all the items from the packing of access point (AP). The following items should be included in the
packaging:
One mounting bracket
SP250/SP250-S5
Waterproof cable gland (*Note)
+ Four screws
One ground wire
One clamp
Note: provides two waterproof cable glands.
2.2. Installation Requirements
TERMS OF USE: All Ethernet cabling runs suggest using CAT.6, 24 AWG (or above) Shielded Twisted Pair (STP) cabling.
In addition, please cut the cable into a proper length, strip the cables on both ends, and crimp the wires into RJ45
connectors. It is the professional installer's responsibility to follow local country regulations, including operation within
legal frequency channels, output power, indoor cabling requirements, and Dynamic Frequency Selection (DFS)
requirements.
2.3. Physical Ports
The following physical ports are available on the SP250 /SP250-S5.
58-150006-IQN_V1.0
Page 2
