CYBEX Arc Trainer 772A Service Manual page 134

Install linkage rods
1. Install linkage rod on crank arm.
2. Place a drop of Loctite
the shaft.
3. Install SHCS, flat washer, cap and spacer using a 3/16" Allen wrench.
NOTE: SHCS must be tightened to a minimum of 90 lbs-in.
4. Repeat steps for other linkage rod.
Install controller cover
1. Plug incline motor cable into control board.
2. Place the controller cover into position.
3. Install screw securing the cover in place using a Phillips screwdriver.
Cybex 772A, 772AT Arc Trainer Part Number
®
#242 on SHCS and place another drop of Loctite
Page 134 of 202
Item Description
Screw, SHCS .250-20 x
1
.75
2 Flat washer
3 Cap
4 Spacer
5 Linkage rod
®
Item Description
1 Cable tie
2 Incline motor cable
3 Controller cover
4 Control board
5 Screw
Qty.
1
1
1
1
1
#242 into the threads of
Qty.
1
1
1
1
1
