Desk Clamp Designed for Samsung OEM Monitor
Stands
Instruction Manual
SKU: MOUNT-SG04
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-sg04
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-SG04
Summary of Contents for Vivo MOUNT-SG04
- Page 1 Desk Clamp Designed for Samsung OEM Monitor Stands Instruction Manual SKU: MOUNT-SG04 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-sg04 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. - Page 3 STEP 2 Remove Locking Screws (A1) from Upper Clamp (A) using a Phillips screwdriver. Slide Base (A2) out from the clamp. STEP 3 Remove the OEM Base and the Plastic Shroud from your Samsung display following the manufacturer’s instructions. Set screw aside for use in later step.
- Page 4 STEP 4 Install Base (A1) to the monitor stand using M4x20mm Screw (S-A) and a Phillips screwdriver. OEM Monitor Stand STEP 5 Attach the Lower Clamp (B) to Upper Clamp (A) using M8x12mm Screws (S-B) and 5mm Allen Wrench (T-A). Secure clamp assembly to desktop in it’s intended location.
- Page 5 STEP 6 Slide the Samsung monitor with stand onto Upper Clamp (A). Ensure the Sliding Plate (A2) is sliding into the slot on the attached base. NOTE: Two person installation is recommended.
- Page 6 STEP 7 Secure monitor into place using the screws removed in Step 2 and a Phillips screwdriver. STEP 8 The Plastic Shroud can be reinstalled following the manufacturer’s recommended instructions.
