- Page 1 Low Profile Wall Mount Designed for Starlink SKU: MOUNT-SLINK1 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-slink1...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents A (x1) Wall Mount Included Hardware & Tools W-B (x2) W-C (x2) W-A (x2) Concrete M8 Washer ST8x90mm Anchor Screw Tools Needed: Drill Stud Finder Level (0.25” or 0.5” drill bit) Pencil Socket Wrench (8mm Socket) Weight Capacity: 11lbs (5kg)
-
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 WOOD STUD INSTALLATION Use a stud finder to locate stud. Hold Wall Mount (A) on the wall while using a level to make sure Wall Mount is level, then mark drilling locations using a pencil. Using a drill and a 0.25” (6mm) drill bit, drill approximately 3.5” (90mm) deep into marked locations. - Page 5 Wood Stud Cont’d Secure Wall Mount (A) to wall using ST8x90mm Screws (W-A), M8 Washers (W-C), and a socket wrench. CONCRETE/BRICK INSTALLATION Hold Wall Mount (A) on the wall while using a level to make sure Wall Mount is level, then mark drilling locations using a pencil.
- Page 6 Concrete/Brick Cont’d Using a drill and a 0.5” (12mm) drill bit, drill approximately 3.7” (95mm) deep into marked locations. 0.5”(12mm) drill bit 3.7”(95mm) deep Press Concrete Anchors (W-B) into holes and secure Wall Mount (A) to wall using ST8x90mm Screws (W-A), M8 Washers (W-C), and a socket wrench.
- Page 7 STEP 2 Slide the Starlink mast into the Wall Mount (A). Plug the Starlink cable into the Starlink, then route the cable as needed.
