Wall Mount Designed for Sonos Arc Soundbar
Instruction Manual
SKU: MOUNT-SONOS3W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-sonos3w
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-SONOS3W
Summary of Contents for Vivo MOUNT-SONOS3W
- Page 1 Wall Mount Designed for Sonos Arc Soundbar Instruction Manual SKU: MOUNT-SONOS3W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-sonos3w GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303. - Page 4 STEP 2 OPTION A: Wood Wall Place the assembled mount against the wall, no less than 5.5” (140mm) below the TV, and mark drilling locations with a pencil. Use of a level is recommended. Mark four drilling locations for a wood panel wall, or two locations for a wood stud wall (use of a stud finder is recommended).
- Page 5 STEP 2 (Continued) OPTION B: Concrete/Brick Wall Place the assembled mount against the wall, no less than 5.5” (140mm) below the TV, and mark four drilling locations with a pencil. Drill 1.8” (45mm) deep holes using a 5/16” (8mm) drill bit, press ST8x40 concrete anchors (W-B) into the holes, then install the mount using ST4.8x50 screws (W-A) using a Phillips screwdriver.
- Page 6 STEP 3 Screw the knobs (D) into the back of the Sonos Arc soundbar.
- Page 7 STEP 4 Hang the Sonos Arc soundbar over the top of the mount, making sure the knobs (D) are inserted into the slots.
