FlexShade Ascend
®

Section 1 - Installing Mounting Brackets or Endcaps

IMPORTANT: Brackets or Endcaps must be installed parallel, plumb, and square, with a tolerance of +/- 1/ 8 "
Verify unit measurements and ensure unit will fit in the desired location.
Please Note: Installer is responsible for selecting mounting hardware appropriate for site conditions.
UNIVERSAL MOUNTING BRACKETS INSTALLATION
1.
Mark wall, jamb, or
ceiling for placement
of mounting brackets.
ENDCAP INSTALLATION
1.
Remove the plastic chain diverter by
prying it off with a small screwdriver.
(Large Endcap Hardware shown.)
2.
Drill small starter
hole
(if necessary)
mounting surface.
2.
Mark wall, jamb, or
ceiling for placement
of mounting endcaps.
3.
Drill small starter
hole
(if necessary)
in mounting surface.
4.
Snap endcap
(Optional)
covers onto endcaps.
3.
Mount brackets
in using appropriate
fasteners for surface.
5.
Mount endcaps using
appropriate fasteners
page 3 of 8
.
(3mm)
for surface.
