1 — ASSEMBLY
F I G 1.1 (P O S I T I O N B A S E & L E V E L)
Position the base in the desired location. Check levelness and adjust
base levelers if necessary.
F I G 1.3 ( TO P P L AT E AT TAC H M E N T )
Attach the top plate to the base using 5/16-18 x 1-1/4" Hex Head Serrated
Flange Bolts and 5/16-18 Serrated Hex Nuts.
TI0085 - Foundation Tapered Drum Base Installation Guide
F I G 1.2 (S A N D B AG W E I G H T P L AC E M E N T )
Insert 2x sandbags into the base. Position sandbags at opposite ends for
stability.
Note: For smaller bases, sandbags may need to be inserted from the
underside of the base.
F I G 1.4 ( WO R KS U R FAC E AT TAC H M E N T )
Place the worksurface on the base. Make sure to align the worksurface
pockets with the ribs located in the top plate. Use #10 X 1" Phillips Pan Head
screws to secure the connection.
