Genion One - Installation Manual
ENVIRONMENTAL CHARACTERISTICS
Working temperature
-20ºC ... +50ºC
Storage temperature
-25ºC ... +75ºC
Relative humidity (non-condensing)
5% ... 95%
Maximum altitude
2000 m
IP degree of protection
IP20
IK degree of protection
IK08
Pollution degree
2
Application
Interior
MECHANICAL CHARACTERISTICS
Terminals
1 ... 13
1.5 mm
0.2 Nm
M2
2
Dimensions
105 x 89 x 49.5 mm
Weight
150 g
Envelope
Polycarbonate UL94 V0 self-extinguishing
Fixing
DIN rail
ELECTRICAL SAFETY
Protection against electric shock
Class II double insulation
Insulation
3 kV~
36
