Genion One - Installation Manual
6
A
Genion One has an RS-485 communications port for communicating with
EV charging points.
The RS-485 cable should be composed of a twisted pair cable with a
shielding sheath (minimum 3 wires), with a maximum distance between
the Genion One and the satellite equipment of 1200 metres.
Genion One
Genion One
16
RS-485 communications
B-
A+
GND
eHome Link
eHome Link
A+
B-
GND
eHome Link
eHome Link
A+
B-
GND
