- Page 1 FLIPPER INSTALLATION, OPERATING AND MAINTENANCE GUIDE...
-
Page 2: Table Of Contents
I GENERAL ......................3 II WARNINGS ......................3 III INSTALLATION ....................4 III.1 Preliminary Indications ..................4 III.2 Fixing the hood to the cabinet ................5 III.3 Electrical Connection ..................5 IV USE ........................ 5 V OPERATION ....................... 6 V.1 Adjustable and delayed self -switching off .............. 6 V.2 Maintenance reminder .................. -
Page 3: I General
I GENERAL Installation, operating and maintenance instructions for cooker hood model SILENZIO. 120V – 60HZ READ AND SAVE THESE INSTRUCTIONS II WARNINGS CAUTION: Automatically Operated Device – To Reduce The Risk Of Injury Disconnect From Power Supply Before Servicing. WARNING: To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any Solid -State Speed Control Device. -
Page 4: Installation
READ AND SAVE THESE INSTRUCTIONS Keep these instructions in a safe place and pass them on to any future user. Read these instructions carefully before installing or using the range hood. Before connecting the appliance to the power supply make sure that the voltage (V) and frequency (Hz) listed on the data plate correspond with the household electrical supply. -
Page 5: Iii.2 Fixing The Hood To The Cabinet
III.2 Fixing the hood to the cabinet To install the hood (Fig. 3.2.1) in the wall unit, the measurements in Fig. 3.2.2 must be observed. Follow the steps indicated below: Remove the metal filters (Fig. 6.2.1) to access the inside of the hood (Fig. 3.2. 3). Insert the hood in the wall unit, taking care to slot the back panel of the wall unit into the relevant seat (Fig. -
Page 6: Operation
V OPERATION The hood is supplied with a multispeed blower. The hood should be run at low speed under normal conditions and at higher speeds only when there is a heavy build- up of fumes or odors. Ideally, the hood should be switched on as soon as cooking is started and then kept on until all odors have been eliminated. -
Page 7: Maintenance And Cleaning
VI MAINTENANCE AND CLEANING Warning! Before any maintenance or cleaning operation, disconnect the hood from the power supply by setting the main switch of the domestic system to "off". VI.1 Metal grease filter Particular attention should be paid to the metal grease filter, which has the function of retaining the fat particles contained in the vapors. - Page 8 3.1.1 3.1.2...
- Page 9 3.2.1 3.2.2...
- Page 10 3.2.3 4.1 DUCTED MODE 4.2 DUCTLESS MODE...
- Page 11 6.1.1 6.2.1...
