  • Page 1 Futuro Futuro Folio Designer Range Hood Installation & User’s Manual...
  • Page 2 Overall Dimensions 33.5” 16” 4.2” 27.6” Weight: 55 lbs. (25 kg) Must be attached to load-bearing component (joist/frame/plywood), NOT to bare sheetrock. General Components Location Duct Output Collar Locations: d i a Top or Rear 6 ” 6 ” d i a 6 ”...
  • Page 3 Ducted installation - vertical blower output Mounting, Part I: It is recommended for the center of the range hood to be approximately 26” - 28” above the cooktop, for best capture performance. 1.) Measure 16”-18” from the cooktop to the bottom of the hood.
  • Page 4 Backdraft Damper Installation A backdraft damper is supplied with the range hood. For DUCTED installation, it’s strongly recommended to DISCARD this damper, and use a damper built into the end-cap (wall or roof cap). For DUCTLESS installation: insert the damper as shown into the blower output collar, open the blades, and secure the damper with the provided screw.4.) Attach the bracket to the wall.
  • Page 5 Ducted installation - rear (horizontal) blower output Mounting, Part I: It is recommended for the center of the range hood to be approximately 26” - 28” above the cooktop, for best capture performance. 1.) Measure 16”-18” from the cooktop to the bottom of the hood.
  • Page 6 Ducted installation - rear (horizontal) blower output Blower Motor Repositioning Remove the blower, remove the knock-out plate (1), and re-install the blower in new direction, repeating the steps described on the previous page in reverse.
  • Page 7 Bottom Panel Operation Filters Installation Carbon (charcoal) Filters Metal Mesh Filters ONLY for DUCTLESS installation For ducted AND ductless installation...
  • Page 8: Safety Instructions And Warnings

    The electric circuit to which the hood is to be connected must be: * In compliance with local electrical standards, * Properly grounded, * Dedicated, not shared with other appliances or dimmable lights.
  • Page 9: Electrical Connection

    The duct (air pipe) must have: * A diameter of 6” throughout its entire run, including the end-cap (roof or wall cap). * A slight slope downward in horizontal sections - to prevent condensation from dripping back into the blower motor. * Minimum number of angles &...
