Product Overview

Short description

The UltraCharge 160 is an integrated DC fast charger that features high efficiency and
flexible configuration. It supports the charging of two vehicles at the same time at same
time and meets the charging demand of larger capacity and high endurance electric
vehicles.

Charger Models

Station Connection
Level Type
1x CCS2
60kW DC
1x CHAdeMO
80kW DC 2x CCS2
120kW DC 2x CCS2
160kW DC 2x CCS2

Product Views

EVUCM-001-V01R1 Installation and Operation Manual
October 2023
Power Allocation
1x 60kW
1x 40kW / 1x20kW*
1x 80kW
2x 40kW*
1x 120kW
2x 60kW*
1x 160kW
2x 80kW*
*When 2 vehicles are charging simultaneously
Figure 1 External View
Product Overview
Input Input
Current Power Colour
112A 67kVA
150A 89kVA
224A 133kVA
299A 177kVA
UltraCharge 160 DC Charger
Unit Product
Code
White EVDC2010
White EVDC2020
White EVDC2030
White EVDC2040
Page 8 of 30
