Product Overview

The BasicCharge is a simplistic and affordable EV charging pedestal. This versatile charger's
integrated LED amenity lighting also provides greater visibility of the charging bays and
surrounding areas.
This future-proof OCPP compliant pedestal can offer a simple plug & charge or pay-to-charge
solution via the EV driver's smartphone and/or RFID card/fob through any chosen OCPP back-
office management system.
Feature-rich, this EV charger supports dynamic load balancing and is equipped with PME fault
detection, so there is no requirement for an earth rod, reducing installation costs. Available in
1way or 2way versions, providing up to 22kW superfast charging.
The BasicCharge Intelligent EV Charging Pedestal is available with the following power and
'standard' enclosure colour options:
Model Number Specification
BasicCharge Intelligent EV Charging Pedestal - 1x up to 7.4kW Type 2 Socket - Black
ROLEC0211B
ROLEC0211G BasicCharge Intelligent EV Charging Pedestal - 1x up to 7.4kW Type 2 Socket - Grey
ROLEC0211W BasicCharge Intelligent EV Charging Pedestal - 1x up to 7.4kW Type 2 Socket - White
BasicCharge Intelligent EV Charging Pedestal - 2x up to 7.4kW Type 2 Sockets - Black
ROLEC0221B
BasicCharge Intelligent EV Charging Pedestal - 2x up to 7.4kW Type 2 Sockets - Grey
ROLEC0221G
BasicCharge Intelligent EV Charging Pedestal - 2x up to 7.4kW Type 2 Sockets - White
ROLEC0221W
BasicCharge Intelligent EV Charging Pedestal - 1x up to 22kW 3PH Type 2 Socket - Black
ROLEC0213B
BasicCharge Intelligent EV Charging Pedestal - 1x up to 22kW 3PH Type 2 Socket - Grey
ROLEC0213G
BasicCharge Intelligent EV Charging Pedestal - 1x up to 22kW 3PH Type 2 Socket - White
ROLEC0213W
BasicCharge Intelligent EV Charging Pedestal - 2x up to 22kW 3PH Type 2 Sockets - Black
ROLEC0223B
BasicCharge Intelligent EV Charging Pedestal - 2x up to 22kW 3PH Type 2 Sockets - Grey
ROLEC0223G
BasicCharge Intelligent EV Charging Pedestal - 2x up to 22kW 3PH Type 2 Sockets - White
ROLEC0223W

Product Features

Plug & charge, mobile app or RFID controlled
charging
Choose from 1x or 2x universal charging
socket(s)
Up to 7.4kW or 22kW charging output(s)
TruePEN PME fault detection (no earth rod
required)
Supports dynamic load balancing & static load
management
OCPP 1.6 compliant (Can integrate with any
compatible back-office)
Over-the-air firmware / software updates
Built-in AC overload & fault current protection
(RCBO)
NOTES:
Where mobile communications will be used, a signal strength of 14 CSQ or better is required at the
chargepoint.
Where Wi-Fi will be used the chargepoint must be in range of a wireless access point and the signal
must be strong and stable at the chargepoint. Users may need to consider an external antenna and/or
booster to their Wi-Fi system to reach remote chargepoints.
For Commercial installations, VendElectric is Rolec EV's chargepoint management platform. Other
preferred partners are: Monta, Fuuse, and ChargePlace Scotland, but others include Parkable and
Ampeco.
For Domestic installations, our preferred partner is Monta who include 3 years free app connectivity
and support. Other preferred partners include ev.energy and Electric Miles.
EVBM-V01-R1 Installation and Operation Manual
December 2022
Built-in 6mA DC leakage protection
Cable lock security feature (can be
permanently locked by user)
Integrated RFID sensor
LED amenity lighting head (Photocell
controlled)
MID-approved energy metering
4G / Wi-Fi / Ethernet connectivity
IK10 impact resistant design
Surface or root mountable
OZEV grant fundable
Designed & manufactured in the UK
BasicCharge Intelligent EV Charging Pedestal
Product Overview
Page 4 of 36
