Linear Technology DC2455A-C Demo Manual page 6

DEMO MANUAL DC2455A-C
parts List
ITEM QTY
39 1
40 1
41 1
42 4
43 1
44 1
45 1
Additional Demo Board Circuit Components
1 0
2 0
3 0
4 0
5 13
6 0
7 1
8 4
9 1
Hardware: For Demo Board Only
1 11
2 0
3 2
4 4
5 5
6 6
7 12
8 6
9 6
10 2
11 5
12 4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE
R104
R105
R106
U1, U2, U3, U4
U5
U6
U7
CO3, CO9, CO14, CO17, CO18, CO38, CO40,
CO42, CO45, CO46
CO4, CO10, CO12, CO19, CO23, CO25,
CO29, CO31, CO37, CO39, CO41, CO43,
CO44, CO47, CO49, CO51, CO53
C2, C3, C5, C8, C9, C12, C17, C20, C21, C29,
C30, C32
R5, R7, R8, R10, R30, R37, R38, R42, R44,
R48, R49, R50, R52, R53, R55, R61, R64,
R87
R6, R19, R20, R27, R28, R32, R33, R35,
R40, R45, R62, R63, R91
R13
R34
R22, R23, R24, R26
R60
E1-E4, E6-E9, E12, E13, E22
E5, E10, E11, E14, E15, E16, E17, E18, E23,
E24, E25, E26, E27, E28, E29, E30
E33, E34
JP1, JP2, JP9, JP10
JP4, JP5, JP6, JP7, JP8
J1, J2, J3, J4, J13, J14
J1, J2, J3, J4, J13, J14 (×2)
J1, J2, J3, J4, J13, J14
J1, J2, J3, J4, J13, J14
J11, J12
XJP1, XJP2, XJP4, XJP9, XJP10
MTGS AT 4 CORNERS
PART DESCRIPTION
RES, 0603 1kΩ 1% 1/10W
RES, 0603 105kΩ 1% 1/10W
RES, 0603 80.6kΩ 1% 1/10W
IC, VOLTAGE REGULATOR, BGA
IC, TimerBlox ®
IC, OP-AMP , SINGLE, BIPOLAR
IC, LTC3630EMSE
CAP , 1210 OPTION
CAP , 7343 OPTION
CAP , 0603 OPTION
RES, 0603 OPTION
RES, 0603 0 OHMS JUMPER
RES, 0603 OPTION
RES, 0603 0Ω JUMPER
RES, 2010 0Ω JUMPER
RES, 1206 0Ω JUMPER
TESTPOINT, TURRET, .063"
TEST PAD SMD
TESTPOINT, TURRET, .094"
HEADER, 3 PIN 2mm SINGLE ROW
HEADER, 2 PIN 2mm SINGLE ROW
STUD, TEST PIN
NUT, BRASS PL # 10-32
LUG RING, #10
WASHER, TIN PLATED BRASS
CON, BNC, 5 PINS
SHUNT 2mm
STAND-OFF , NYLON
MANUFACTURER/PART NUMBER
VISHAY, CRCW06031K00FKEA
VISHAY CRCW0603105KFKEA
VISHAY CRCW060380K6FKEA
LINEAR TECH., LTM4650EY-1#PBF
LINEAR TECH., LTC6992IS6-1B#PBF
LINEAR TECH., LT1803IS5#PBF
LINEAR TECH., LTC3630EMSE#PBF
OPTION
OPTION
OPTION
OPTION
VISHAY, CRCW06030000Z0EA
OPTION
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW20100000ZEA9
VISHAY, CRCW12060000ZOEA
MILL MAX, 2308-2-00-80-00-00-07-0
MILL MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 620-003-111-21
WURTH ELEKTRONIK, 620-002-111-21
PEM, KFH-032-10
ANY, 10-32M/S BR PL
KEYSTONE, 8205
ANY, #10EXT BZ TN
CONNEX, 112404
WURTH ELEKTRONIK, 608-002-134-21
KEYSTONE, 8833
