Settings overview

Temp. min. (flow temp. limit, min.)
Temp. max. (flow temp. limit, max.)
Limit (return temp. limitation)
Gain - max. (return temp. limitation - max. influence)
Gain - min. (return temp. limitation - min. influence)
Intgr. time (time constant for return temp. limitation)
Auto tuning
Motor prot. (motor protection)
Xp1 at 65 C (proportional band)
Xp2 at 90 C (proportional band)
Tn (integration time constant)
Tn - idle (integration time constant)
M1 run (running time of the motorized control valve)
Nz (neutral zone)
Open time
Close time
S2 idle
P1 exercise (pump exercise)
M1 exercise (valve exercise)
P1 frost T (frost protection)
P1 heat T (heat demand)
Standby T (standby temperature)
Ext. (external override)
Min. on time (min. activation time gear motor)
Daylight (daylight saving time changeover)
ECL address (master / slave address)
Type
Code no.
Ver. (version no.)
Backlight (display brightness)
Contrast (display contrast)
Language
MOD address (MODBUS address)
6 | © Danfoss | 2020.12
Factory
Line Page
setting
2177 10 10 °C
2178 10 90 °C
4030 11 50 °C
4035 12 0.0
4036 12 0.0
4037 13 25 s
6173 14 OFF
6174 15 OFF
6184 15 50 K
6129 15 120 K
6185 16 20 s
6096 16 120 s
6186 16 15 s
6187 17 3 K
6094 18 OFF
6095 18 2.0 s
6097 18 OFF
7022 19 OFF
7023 19 OFF
7077 19 10 °C
7078 19 20 °C
7093 20 10 °C
7141 20 OFF
7189 20 3
7198 21 ON
7199 21 15
7600 22 116
8300 23 XXXX
8301 23 XXXX
8310 23 16
8311 23 10
8315 24 English
8320 24 5
