Ruijie RG-AP180 Quick Installation Manual page 3

Note:
1 The access point can be powered either with a DC poweradapter or through Power
over Ethernet (PoE).
2 When powering the device through PoE，you need toconnect one end of an
Ethernet cable to the uplink port andthe other end to a PoE-capable switch or any
powersourcing equipment.
3 When powering the device through DC power adapter, youneed to connect one
end of an Ethernet cable to the uplinkport and the other end to a switch.
Button and LED Indicators
The LED indicator is inside of top plate cover, and works afteryou power on the
device.
You can also use the quiet-mode and schedule commands onthe AP or AC
device to configure the quiet time range.
Table 1-2 Button and LED Indicators on RG-AP180
States
OFF
Solid green after fast
Blinking
Fast Blinking Red
Orange Blinking
Green Blinking
Green Blinking
Reset Button
Frequency
N/A
Fast blinking: 2.5Hz
Fast Blinking: (2.5Hz)
Blinking (1H)
Blinking (1Hz)
Blinking (0.4Hz)
Press for less 2seconds
Press for more than3
seconds
Meaning
The AP is NOT receiving power. Or
the AP is in Do Not Disturb Mode.
which can be disabled by software
lnitialization in progress Normal
Operation.
Firmware upgrade in progress.
Do not power off.
Normal Operation. But the WAN
Portis LinkDown.
Normal Operation, and the WAN
portis LinkUp. NO CAPWAP.
Normal Operation. The CAPWAP
works normally, and at least one
wireless client is associated with the
AP
Reset the system
Reset the system and restore the
factory settings(namely ,the AP is
operating in FIT mode)
