Summary of Contents for Knoll Stroke 665/420
Page 1
Tone Electric & Extended Electric— Stroke 665/420 User Manual Knoll, Inc. Customer Service 1235 Water Street East Greenville, PA 18041...
Page 2: Table Of Contents
Servicing of double-insulated products Appendix Dimensions column system: Tone Extended Electric with 665 stroke Dimensions column system: Tone Electric with 420 stroke Accessories, Tone Electric & Extended Electric ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 2...
Page 3: Important Information-Safety First
Knoll reserves the right to discontinue or change specifications or design at anytime without notice and without incurring any obligation whatsoever. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 3...
Page 4: Important Safety Instructions. Please Save These Instruction
9. Do not use outdoors. 10. Do not operate the table in a potentially explosive atmosphere. 11. To disconnect, turn all controls to the off position, then remove plug from outlet. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 4...
Page 5
To 14. The table must not be structurally or technically prevent damage, use only components recommended altered or modified in any way. by the manufacturing company. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 5...
Page 6: User Information
3.2. 1.4 Electrical rating Electrical rating, input: 120VAC, 50-60Hz, 3,2A. Output 35V. Typical Product Label with Date of Manufacture Typical power supply label ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 6...
Page 7: Assembly & Adjustment
4. Assemble the power cord to the power supply. P/N: KR68002262. 5. The table is ready for use, connect the power cord to the outlet. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 7...
Page 8: Optional Mounting Guidelines
3 Handset This product is designed for the voltage indicated on the power supply label. No adapters should be used with this product. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 8...
Page 9: Adjustments
The control unit might be damaged by power surges. Unplug the power cord during a thunderstorm or if you do not intend to use the desk for a longer period. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 9...
Page 10: Operation Instructions
If a motor (or electronic) has been disconnected from the during all resets and limit position calibration. column, during or after the assembly, a reset (homing) cycle MUST be performed. A reset (homing) cycle ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 10...
Page 11: Maintenance & Repairs
Soft start – Progressive acceleration allows for soft starts and stops. Speed – the speed of the table varies with load. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 11...
Page 12: Servicing Of Double-Insulated Products
A double insulated product is marked with the words ”DOUBLE INSULATION” or ”DOUBLE INSULATED”. The symbol (square within a square) is also able to be marked on the product. ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 12...
Page 13: Appendix
5 Appendix 5.1 Dimensions column system: Tone Extended Electric with 665 stroke ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 13...
Page 14: Dimensions Column System: Tone Electric With 420 Stroke
5.2 Dimensions column system: Tone Electric with 420 stroke ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 14...
Page 15: Accessories, Tone Electric & Extended Electric
Length 31-½", P/N KR68002414 Length 47", P/N KR68003122 Length 63", P/N KR68002583 Length 78", P/N KR68002489 Bus splitter, P/N KR68003690 68004634 - D © ROL USA Inc ©Knoll, Inc. Tone Electric & Extended Electric - Stroke 665/420 User Manual 15...
