Wide Grommet
Reference Number: 6TD00064
HARDWARE LIST
A
B
6TD40165
SCR,
6TD40157
FLT#6-32x0.875
COVER HINGE PIN
STEPS:
1. Assembly of cover frame
1.1 Align the connector rails (E), with one of
bridge assembly (F), and secure into
place using 1 screw (A) for each rail,
ensure correct orientation of connector
rail as per Fig. 1.
1.2 Align the other ends of connector rails (E),
with second bridge assembly (F), and
secure into place using 1 screw (A) for
each rail.
(Fig. 2)
1.3 Align & assemble 4 thumbscrews (C), into
bridge support of bridge assembly (F),
ensure threads do not extend beyond exit
whole edge.
(Fig. 3)
Islands Collection by Knoll
®
Novemberr 23, 2020
C
D
6TD40148
6TD00016XX
SCR,
WIDE GROMMET
THUMB,10-24x0.500
ASSEMBLY
6td00064_1_hardware.ai
Fig. 1
F
Fig. 2
Fig. 3
Islands Collection by Knoll
E
F
6TD40154XX
6TD00028
CONNECTOR RAIL
BRIDGE ASSEMBLY
E
Bridge support
6td00064_2.ai
Installation Instruction
®
Tools Needed
Drill gun
G
6TD40153XX
WIDE GROMMET
COVER
A
C
Part Number: 6TD00064
Sheet 1
