TASKING iSYSTEM Infineon TC234LF Hardware User Manual page 12

P2: Power supply configuration
Emulation Adapter Power supply is configured via the unshrouded 26-pin 2.54 mm header (P2).
Signal Direction
target
target
target
Refer to the microcontroller user's manual for more details which power supply designation in
the above table belongs to which power supply.
By default all jumpers are set and connect target power supply coming from the target to the mi-
crocontroller residing on the emulation adapter. In principle, pins 3-4, 5-6, 7-8, must be bridged
only but for the convenience and ease of use, all jumpers are set except for pins 25-26. Pin 26 is
the polarizer key preventing incorrect connection of the IEA-PS power supply, when connected.
Signal Pin
VDDP3 1
VDDM 3
VAREF 5
NC 7
NC 9
NC 11
NC 13
NC 15
NC 17
NC 19
GND 21
GND 23
GND 25
P2 Signal description
Pin Signal
2 CVDDP3/3v3
4 CVDDM
6 CVAREF
8 NC
10 NC
12 NC
14 NC
16 NC
18 NC
20 NC
22 GND
24 GND
26 KEY
Signal Direction
CPU
CPU
CPU
