evertz 7700 Manual

Quartz remote control to mvs protocol translator
Hide thumbs Also See for 7700:
Table of Contents

Advertisement

Quick Links

Download this manual
1.
OVERVIEW ..................................................................................................................................... 1
2.
CARD EDGE CONTROLS.............................................................................................................. 2
2.1. DETERMINING CURRENT IP ADDRESS SETTINGS .......................................................... 2
2.2. RESTORING FACTORY DEFAULTS.................................................................................... 2
2.3. CARD EDGE LEDS ............................................................................................................... 2
3.
TECHNICAL SPECIFICATIONS..................................................................................................... 3
3.1. DATA INPUT SERIAL PORT................................................................................................. 3
3.2. ELECTRICAL......................................................................................................................... 3
3.3. PHYSICAL ............................................................................................................................. 3
4.
CONFIGURATION .......................................................................................................................... 4
4.2. EXAMPLE CONFIGURATION: TALLIES.............................................................................. 6
AND/OR VGPI (TALLY) DATA.............................................................................................. 7
4.4. STEP 2: CONNECT 7700PTX-MVS TO THE SWITCHER .................................................... 8
4.5. STEP 3: CONNECT A PC TO THE DEBUG/MONITOR PORT............................................. 9
4.6. STEP 4: CONFIGURE NETWORK PARAMETERS............................................................ 11
4.7. STEP 5: OPEN 7700PTX-MVS VLPRO CONFIGURATION VIEW ..................................... 13
4.8. STEP 6: CONFIGURE SWITCHER PARAMETERS ........................................................... 14
4.9. STEP 7: CONFIGURE UMD/VGPI (TALLY) PEERS........................................................... 17
4.10. STEP 8: CONFIGURE ROUTER PARAMETERS (OPTIONAL) ......................................... 18
4.11. STEP 9: REBOOT THE 7700PTX-MVS .............................................................................. 22
4.12. STEP 10: CHECK SWITCHER COMMUNICATION............................................................ 23
4.13. STEP 11: CHECK UMD/VGPI (TALLY) PEER COMMUNICATION ................................... 25
4.14. STEP 12: CHECK ROUTER COMMUNICATION (OPTIONAL).......................................... 26
DESTINATIONS (OPTIONAL)............................................................................................. 27
SWITCHER SOURCES (OPTIONAL).................................................................................. 28
5.
ROUTER CONTROL..................................................................................................................... 30
5.1. CROSSPOINT CONTROL ................................................................................................... 30
7700PTX-MVS Quartz Remote Control To MVS Protocol Translator

TABLE OF CONTENTS

Revision 1.6
7700 MultiFrame Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for evertz 7700

Summary of Contents for evertz 7700

  • Page 1: Table Of Contents

    7700 MultiFrame Manual 7700PTX-MVS Quartz Remote Control To MVS Protocol Translator TABLE OF CONTENTS OVERVIEW ............................. 1 CARD EDGE CONTROLS......................2 2.1. DETERMINING CURRENT IP ADDRESS SETTINGS ............2 2.2. RESTORING FACTORY DEFAULTS..................2 2.3. CARD EDGE LEDS ....................... 2 TECHNICAL SPECIFICATIONS.....................
  • Page 2 7700 MultiFrame Manual 7700PTX-MVS Quartz Remote Control To MVS Protocol Translator FIRMWARE UPGRADE........................ 31 6.1. FTP PROCEDURE....................... 31 6.2. SERIAL PROCEDURE ......................31 VISTALINK REMOTE MONITORING/CONTROL ..............33 ® 7.1. WHAT IS VISTALINK ?....................... 33 ® Figures Figure 2-1: PTX Card Edge ..........................2 Figure 4-1: Example Setup with Quartz Router....................4...
  • Page 3 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 4 7700 MultiFrame Manual 7700PTX-MVS Quartz Remote Control To MVS Protocol Translator This page left intentionally blank Revision 1.6...
