Specifications
Speed accuracy (open loop)
All control characteristics are based on a 4-pole asynchronous motor
Surroundings
Enclosure type D1h/D2h
Enclosure type D3h/D4h
Vibration test all enclosure types
Relative humidity
Aggressive environment (IEC 60068-2-43) H
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature (at SFAVM switching mode)
- with derating
- with full output power of typical EFF2 motors (up to 90% output current)
- at full continuous FC output current
1)
For more information on derating see the Design Guide, section on Special Conditions.
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
1)
For more information on derating see the Design Guide, section on Special Conditions.
EMC standards, Emission
EMC standards, Immunity
See the Design Guide, section on Special Conditions.
Control card performance
Scan interval
11 11
Control card, USB Serial Communication:
USB standard
USB plug
CAUTION
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is not galvanically isolated from protection earth (ground). Use only isolated laptop/PC as
connection to the USB connector on frequency converter or an isolated USB cable/converter.
Protection and Features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heat sink ensures that the frequency converter trips if the temperature reaches
95° C ±5° C. An overload temperature cannot be reset until the temperature of the heat sink is below 70° C ±5° C
(Guideline - these temperatures may vary for different power sizes, enclosures etc.). The frequency converter has
an auto derating function to avoid its heatsink reaching 95° C.
•
The frequency converter is protected against short-circuits on motor terminals U, V, W.
•
If a mains phase is missing, the frequency converter trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the frequency converter trips if the intermediate circuit
voltage is too low or too high.
•
The frequency converter is protected against earth (ground) faults on motor terminals U, V, W.
82
Operating Instructions
5%-95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
S test
2
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
Danfoss A/S © Rev. 2014-02-20 All rights reserved.
30-4000 rpm: Maximum error of ±8 rpm
IP21/Type 1, IP54/Type12
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EN 61800-3, EN 61000-6-1/2,
USB type B "device" plug
IP20/Chassis
1.0 g
class Kd
1)
max. 55° C
1)
max. 50° C
max. 45° C 1)
0° C
- 10° C
-25 to +65/70° C
1000 m
3000 m
5 ms
1.1 (Full speed)
