Scroll compressors, VCH115 | Introduction

Introduction

Product description

Danfoss scroll compressor VCH115 for R410A is optimized for China low ambient heat pump and modular chiller
application.

Cut Away VCH115

Figure 1: Cut Away VCH115

Vapor injection

The VCH115 compressor is tted with an injection port that enables to carry out vapor injection by connecting an
intermediate exchanger.
This vapor injection will have three bene ts:
• Operating envelope enlargement by reduction of resulting discharge temperature.
• Cooling capacity and cooling e ciency improvement by reduction of the liquid temperature before expansion
(Intermediate exchanger acting as economizer).
• Heat capacity and heating e ciency improvement by increase of the mass ow at the condenser side (condenser
mass ow will be the sum of the evaporator mass ow and the injected mass ow).
The diagrams below explain the vapor injection principle, considering:
m inj: Injected mass ow
ΔT IntX: Di erence of temperature between the outlet of intermediate exchanger and the intermediate pressure
bubble point.
© Danfoss | Climate Solutions | 2023.08
1 Optimize scroll sets PR, combine vapor injection,
and optimize e ciency in heat pump application
2 Increase injection pipe diameter, and reduce pipe
vibration
1
3 Optimize structure design, reduce compressor
acoustic at high speed
4 New designed high e ciency motor, improve
e ciency at Part- load condition
2
5 Oil strainer reduce the oil stirring when
compressor running
6 Compact compressor outline design, bene cial for
3
system unit layout
4
5
6
