Scroll compressors, VCH115 | Product identi cation

Product identi cation

Name Plate

Figure 2: Name Plate
型号 :
VCH115DGENA
1
序列号 :
MK2500000123
2
注意：变频压缩机只能丹佛斯认证过的变频器供电
制冷剂: R410A
3
受国内外专利保护

Nomenclature

The example below presents the compressor nomenclature which equals the technical reference as shown on the
compressor nameplate. Code numbers for ordering are listed in section Ordering.
V
Variable speed
Family
VCH scroll,
for China market
Lubricant
POE lubricant,
R410A refrigerant
Swept volume
in cm³/rev
Design pressure ratio
D: Vapor injection,
heating optimized

Compressors serial number

Year code
Month code
Plant assembly line code
© Danfoss | Climate Solutions | 2023.08
中 国 制 造
I
380 V3 ~ 50 Hz
连接 CDC100 变频器
热电保护系统
设计压力 低压 高压
压力
33.3 bar 48.7 bar
最高温度
55 °C 150 °C
最低温度
-35 °C -35 °C
容量
10.6 L 0.85 L
润滑剂 :P.O.E. 160SZ
频率 :90-420 Hz
速度 :30-140 rps
最大运行电流 : 65A
C H 115 D
A B 25
1 Model number
2 Serial number
3 Refrigerant
4
4 Supply voltage to CDC frequency converter
5 Housing service pressure
5
6 Factory charged lubricant
6
7
7 Compressor frequency & Max operating current
G E N A
12345678
Evolution index
Motor protection type
N: no internal motor protection
(protection by drive)
Equipement version
E: brazed connection, no oil sight glass,
IP22 E-box
F: brazed connection, no oil sight glass,
IP54 E-Box
Motor voltage code to CDC100*
G: 380 V/ 3~ / 50 Hz
* main supply voltage to frequency converter
8 Digit serial number
AB392939083370en-000202 | 7
