Scroll compressors, VCH115 | Electrical connections
Figure 10: terminal box for VCH115 with IP54 E-Box
1
2
3

Electrical speci cations

IP rating
VCH115 compressor terminal box IP rating according to IEC60529 is IP22 after installing the U Plug 120Z0852 on the
E-Box.
VCH115 with IP54 E-Box compressor terminal box IP rating according to IEC60529 is IP54 when correctly sized IP54
rated cable glands are used.
Element
First characteristic numeral
Against ingress of solid foreign objects
Second characteristic numeral
Against ingress of water with harmful
e ects
MCCB / FUSE / Contactor
Danfoss recommends using the fuses/circuit breakers to protect service personnel and property in case of
component break-down in the frequency converter.
Table 9: MCCB / FUSE / Contactor
Model
3 × 380 V 25TR/VCH115
© Danfoss | Climate Solutions | 2023.08
Numerals or letters
0
1
2
3
4
5
6
0
1
2
3
4
5
6
7
8
Power
model
[kW]
30 CDC100
1 Ø 16.5mm (φ0.65inch) knockout
2 Ø 40.5mm (φ1.59inch) hole
3 Power supply
Meaning for the protection of equipment
(non protected)
≥ 50 mm diameter
≥ 12.6 mm diameter
≥ 2.5 mm diameter
≥ 1.0 mm diameter
(non protected)
vertically dripping
dripping (15° tilted)
powerful jetting
temporary immersion
continuous immersion
MCCB Contactor
[A] [A]
100 100
dust protected
dust tight
spaying
splashing
jetting
Recommended circuit
gG fuse
breaker
Maximum fuse IP20
[A] Moeller type
80 NZMB1-A100
AB392939083370en-000202 | 19
