GW1NR series of FPGA products
Package & Pinout User Guide
UG119-1.7.1E, 12/14/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GW1NR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GOWIN GW1NR Series

Summary of Contents for GOWIN GW1NR Series

  • Page 1 GW1NR series of FPGA products Package & Pinout User Guide UG119-1.7.1E, 12/14/2023...
