  • Page 1 Pack 02 B U I L D I N S T R U C T I O N S ASSEMBLING THE LEFT SHOULDER & ARM TRANSFORMERS and HASBRO and all related trademarks and logos are trademarks of Hasbro, Inc. ©2022 Hasbro.
  • Page 2 Advice from the experts Please keep ALL unused screws as they may be required in a later stage. Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary slightly. Using the wrong screws may damage the parts. When securing parts together using multiple screws, fit each screw loosely to ensure all the parts are correctly aligned before gently tightening them firmly, but not overtight, in the order in which you placed them.
  • Page 3 Pack 2: Assembling the Left Shoulder & Arm AGORAMODELS OPTIMUS PRIME...
  • Page 4 Pack 2 Parts T R A Y 1 : TR-2-15 TR-2-14 TR-2-19 TR-2-18 M3x14 mm M3x10 mm TR-2-58 M3x6 mm (nut 3) x11 M3x8 mm TR-2-46 x2 TR-2-49 x36 PB2.3x6 mm TR-2-50 x8 TR-2-42 TR-2-25 TR-2-02 TR-2-06 TR-2-30 TR-2-28 TR-2-43 TR-2-48 x4 TR-2-33 TR-2-07...
  • Page 5 Pack 2 Parts T R A Y 2 : TR-2-21 TR-2-03 TR-2-32 TR-2-20 TR-2-34 TR-2-22 TR-2-41 TR-2-44 TR-2-47 x2 TR-2-16 TR-2-29 TR-2-45 x3 TR-2-23 TR-2-26/27 TR-2-10 TR-2-11 AGORAMODELS OPTIMUS PRIME...
  • Page 6 Pack 2 Parts T R A Y 3 TR-2-01 TR-2-05 PB2x4 mm TR-2-12 ‘1’ TR-2-13 ‘2’ PWM2x4 mm TR-2-04 TR-2-35 PWM2x6 mm TR-2-24 TR-2-37 TR-2-31 TR-2-36 TR-2-39 TR-2-38 TR-2-09 TR-2-40 TR-2-08 AGORAMODELS OPTIMUS PRIME...
  • Page 7 Assembling the Left Shoulder & Arm S T E P 1 Align TR-2-14 and TR-2-15 as shown and secure them TR-2-14 together using 2x PB2x4 mm screws. TR-2-15 PB2x4 S T E P 2 Glue the assembly from step 1 as shown in 2a, then fix TR-2-43 over the glued end as shown.
  • Page 8 Assembling the Left Shoulder & Arm TR-2-40 TR-2-02 S T E P 5 First attach TR-2-40 to TR-2-02, PB2.3x6 Fix TR-2-02 to the assembly from step 4 using 1x PB2.3x6 mm screw. TR-2-18 M3x8 TR-2-48 TR-2-49 TR-2-50 S T E P 6 Thread TR-2-49 and TR-2-50 onto a M3x8 mm screw before inserting the assembled screw through a corner screw hole hole in TR-2-18.
  • Page 9 Assembling the Left Shoulder & Arm M3x8 TR-2-49 TR-2-50 TR-2-48 TR-2-25 S T E P 7 Push assembly A into TR-2-25 as shown. Thread washers TR-2-49 and then TR-2-50 onto a M3x8 mm screw. Make 4 sets and then screw them into TR-2-48 as shown.
  • Page 10 Assembling the Left Shoulder & Arm S T E P 8 C O N T . . . IMPORTANT! Check that the red sides are flat. Correct Incorrect S T E P 9 Place a washer TR-2-49 onto a M3x6 mm screw before pushing it through TR-2-19 to attach it to TR-2-46.
  • Page 11 Assembling the Left Shoulder & Arm S T E P 1 1 TR-2-30 Align TR-2-30 with assembly A as shown, then fix it in place using 2x PB2.3x6 mm screws. Pay close attention to the shape of the hole in part TR-2-30, checking that it fits the fixing point on TR-2-46 (shown completed in 11b below).
  • Page 12 Assembling the Left Shoulder & Arm M3x8 TR-2-49 S T E P 1 3 Secure A to B using 4x washers TR-2-49 and 4x screws M3x8 mm as shown. PB2.3x6 TR-2-07 TR-2-06 PB2.3x6 S T E P 1 4 Attach TR-2-07 to assembly A by driving 2x PB2.3x6 mm screws through the tabs (blue arrows) and into the screw posts on TR-2-07 (blue circles).
  • Page 13 Assembling the Left Shoulder & Arm S T E P 1 5 Secure TR-2-27 to A using 4x PB2.3x6 mm screws. TR-2-27 PB2.3x6 TR-2-26 PB2.3x6 S T E P 1 6 Secure TR-2-26 to A using 4x PB2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 14 Assembling the Left Shoulder & Arm TR-2-29 TR-2-11 PB2.3x6 TR-2-47 TR-2-16 S T E P 1 7 Attach TR-2-29 to TR-2-11 and secure them with 2x PB2.3x6 mm screws. Attach TR-2-47 to TR-2-29 Attach TR-2-16 to TR-2-11. Do not glue as this is a moving part. This is now referred to assembly as A.
  • Page 15 Assembling the Left Shoulder & Arm S T E P 1 9 M3x8 TR-2-49 Attach TR-2-20 and TR-2-21 to A. Thread washer TR-2-49 onto screw M3x8 mm and feed through the assembly, securing from the opposite side using a TR-2-58 nut TR-2-58.
  • Page 16 Assembling the Left Shoulder & Arm TR-2-49 TR-2-58 M3x8 TR-2-41 S T E P 2 2 Attach TR-2-41 to A as shown. Thread washers TR-2-49 onto 4x M3x8 mm screws and push them through the assembly as shown, securing them in place from the opposite side using nuts TR-2-58. S T E P 2 3 Attach the assembly from step 22 to the assembly from step 16.
  • Page 17 Assembling the Left Shoulder & Arm TR-2-49 M3x10 TR-2-58 S T E P 2 4 Start by placing TR-2-58 into each notch (shown above right), then place washers TR-2-49 onto 2x M3x10 mm screws before driving them into TR-2-58 as shown. M3x10 TR-2-49 TR-2-58...
  • Page 18 Assembling the Left Shoulder & Arm S T E P 2 6 Position TR-2-03 onto A. TR-2-03 S T E P 2 7 Secure the parts together using 4x PB2.3x6 mm screws. PB2.3x6 AGORAMODELS OPTIMUS PRIME...
  • Page 19 Assembling the Left Shoulder & Arm S T E P 2 8 TR-2-37 Attach TR-2-37 to TR-2-35. TR-2-35 S T E P 2 9 Back of model TR-2-05 Place TR-2-05 on top of TR-2-35 and secure it in place using 4x PWM2x6 mm screws.
  • Page 20 Assembling the Left Shoulder & Arm S T E P 3 1 PWM2x4 TR-2-24 TR-2-04 Place TR-2-24 onto TR-2-04 and secure them together using 4x PWM2x4 mm screws as shown. S T E P 3 2 Place the assembly from step 31 onto the shoulder assembly from step 30, sliding it into position in...
  • Page 21 Assembling the Left Shoulder & Arm S T E P 3 5 Attach the assembly from step 34 to A as shown. PWM2x4 TR-2-12 TR-2-13 TR-2-01 S T E P 3 6 Place TR-2-12 and TR-2 13 on TR-2-01 as shown, securing them with 4x PWM2x4 mm screws.
  • Page 22 Assembling the Left Shoulder & Arm S T E P 3 7 Place the assembly from step 36 onto the shoulder, sliding it into position in the direction of the arrow. PB2.3x6 TR-2-31 TR-2-38 S T E P 3 8 Secure the parts from step 37 in place using a PB2.3x6 mm screw.
  • Page 23 Assembling the Left Shoulder & Arm PB2.3x6 TR-2-09 PB2x4 PB2.3x6 TR-2-08 S T E P 3 9 Position TR-2-08 and TR-2-09 either side of A as shown. Secure them together using 2x PB2.3x6 mm screws in the outer holes, and 1x PB2x4 mm screw in the central hole. TR-2-32 S T E P 4 0 Fix TR-2-32 to A as shown.
  • Page 24 Assembling the Left Shoulder & Arm P A C K 2 C O M P L E T E AGORAMODELS OPTIMUS PRIME...
