- Page 1 Pack 02 B U I L D I N S T R U C T I O N S ASSEMBLING THE LEFT SHOULDER & ARM TRANSFORMERS and HASBRO and all related trademarks and logos are trademarks of Hasbro, Inc. ©2022 Hasbro.
- Page 2 Always protect the paint finish on components by placing a cutting mat, sheet of white paper or soft cloth on your work surface. Left and Right! When building your Optimus Prime, the left or right hand side refers to each side as viewed by Optimus Prime. Optimus Prime’s left arm is on the viewer’s right.
- Page 3 Pack 2: Assembling the Left Shoulder & Arm AGORAMODELS OPTIMUS PRIME...
- Page 4 T R A Y 1 : TR-2-15 TR-2-14 TR-2-19 TR-2-18 PM3x10 x4 PM3x14 x4 TR-2-58 PM3x6 x8 (nut 3) x11 PM3x8 x20 TR-2-46 x2 TR-2-49 x36 PB2.3x6 x31 TR-2-50 x8 TR-2-42 TR-2-02 TR-2-06 TR-2-48 x4 TR-2-30 TR-2-28 TR-2-43 TR-2-33 TR-2-07 TR-2-17 TR-2-59 AGORAMODELS OPTIMUS PRIME...
- Page 5 Pack 2 Parts: T R A Y 2 : TR-2-21 TR-2-03 TR-2-32 TR-2-20 TR-2-34 TR-2-22 TR-2-41 TR-2-44 TR-2-47 x2 TR-2-16 TR-2-29 TR-2-45 x3 TR-2-23 TR-2-26/27 TR-2-10 TR-2-11 AGORAMODELS OPTIMUS PRIME...
- Page 6 Pack 2 Parts: T R A Y 3 TR-2-01 TR-2-05 PB2x4 x5 TR-2-12 ‘1’ TR-2-13 ‘2’ PWM2x4 x9 TR-2-04 TR-2-35 PWM2x6 x5 TR-2-24 TR-2-37 TR-2-31 TR-2-36 TR-2-39 TR-2-38 TR-2-09 TR-2-40 TR-2-08 AGORAMODELS OPTIMUS PRIME...
- Page 7 Apply a little glue to TR-2-33 as shown in 4a and fix TR-2-33 to the assembly from step 3. Study the inset image (bottom, right) to check that part TR-2-33 is in the correct orientation. There is a step at one end . AGORAMODELS OPTIMUS PRIME...
- Page 8 Thread TR-2-49 and TR-2-50 onto PM3x8 before inserting the assembled screw through a corner screwhole hole in TR-2-18. Then attach TR-2-48. Repeat with the other 3 sets, driving them through the remaining 3 screw holes. Fasten each screw quite tight. AGORAMODELS OPTIMUS PRIME...
- Page 9 The top and bottom edges are rounded, the left and right edges are flat (see 8a–d on the next page). Thread TR-2-49 onto PM3x6 and make 4 sets, using them to secure TR-2-46 in place as shown. AGORAMODELS OPTIMUS PRIME...
- Page 10 B as shown. Push the parts together. Thread washers TR-2-49 onto screws PM3x14 and make 4 sets. Fix the parts together as shown, pushing each screw assembly through the four screw holes on PM3x14 TR-2-49 each part. TR-2-28 AGORAMODELS OPTIMUS PRIME...
- Page 11 TR-2-30, checking that it fits the fixing point on TR-2-46 (shown in the completed 11b below). PB2.3x6 TR-2-46 S T E P 1 2 Attach assembly A to assembly B as shown. AGORAMODELS OPTIMUS PRIME...
- Page 12 Attach TR-2-07 to assembly A by driving 2x PB2.3x6 screws through the tabs (blue arrows) and into the screw posts on TR-2-07 (blue circles). Push the lugs on TR-2-06 into TR-2-07, using a little glue as shown in 14a to secure parts together. AGORAMODELS OPTIMUS PRIME...
- Page 13 Pack 2: Assembling the Left Shoulder & Arm S T E P 1 5 Secure TR-2-27 to A using 4x PB2.3x6 screws. TR-2-27 PB2.3x6 TR-2-26 PB2.3x6 S T E P 1 6 Secure TR-2-26 to A using 4x PB2.3x6 screws. AGORAMODELS OPTIMUS PRIME...
- Page 14 This is now referred to assembly as A. PB2.3x6 TR-2-45 TR-2-10 S T E P 1 8 Attach TR-2-10 to assembly A and secure everything together using 3x PB2.3x6 screws. Then place 3x TR-2-45 caps over the screws. AGORAMODELS OPTIMUS PRIME...
- Page 15 S T E P 2 1 Attach TR-2-22 and TR-2-23 to A as shown. Thread washer TR-2-49 onto screw PM3x8 and make 2 sets. Push each screw with washer through the assembly as shown, securing them in place using 2x nuts TR-2-58. AGORAMODELS OPTIMUS PRIME...
- Page 16 Attach the assembly from step 22 to the assembly from step 16. Push into position, lining up the screw holes. Start with one screw hole, get it into position, then follow with the second screw hole, as demonstrated by the sequence above. AGORAMODELS OPTIMUS PRIME...
- Page 17 Start by placing TR-2-58 into each notch (shown above right), then place washers TR-2-49 onto screws PM3x10 before screwing them into TR-2-58 as shown. PM3x10 TR-2-49 TR-2-58 S T E P 2 5 Turn the assembly over and repeat step 24 on the opposite side. AGORAMODELS OPTIMUS PRIME...
- Page 18 Pack 2: Assembling the Left Shoulder & Arm S T E P 2 6 Position TR-2-03 onto A. TR-2-03 S T E P 2 7 Secure the parts together using 4x PB2.3x6 screws. PB2.3x6 AGORAMODELS OPTIMUS PRIME...
- Page 19 Front of model and forwards from the back PWM2x6 to the front. PB2.3x6 S T E P 3 0 Place assembly A onto the shoulder assembly from step 27, securing it in place using 4x PB2.3x6 screws. AGORAMODELS OPTIMUS PRIME...
- Page 20 Secure the parts from step 32 in position using a PB2.3x6 screw, then TR-2-39 push TR-2-39 into A until it clicks into position. S T E P 3 4 TR-2-36 Place TR-2-34 onto TR-2-36 and secure them using a PB2x4 screw. PB2x4 TR-2-34 AGORAMODELS OPTIMUS PRIME...
- Page 21 Apply a drop of super glue to the assembly from step 34 before attaching it to A as shown. PWM2x4 TR-2-12 TR-2-13 TR-2-01 S T E P 3 6 Place TR-2-12 and TR-2 13 on TR-2-01 as shown, securing them with 4x PWM2x4 screws. AGORAMODELS OPTIMUS PRIME...
- Page 22 Secure the parts from step 37 in place using a PB2.3x6 screw. Push TR-2-38 into A as shown until it clicks into place. Apply a little glue to TR-2-31 as shown in 38a, then fix it to A. AGORAMODELS OPTIMUS PRIME...
- Page 23 Secure them together using 2x PB2.3x6 screws in the outer holes, and 1x PB2x4 screw in the central hole. TR-2-32 S T E P 4 0 Apply a little super glue to TR-2-32 as shown in 40a and fix it to A. AGORAMODELS OPTIMUS PRIME...
- Page 24 Pack 2: Assembling the Left Shoulder & Arm P A C K 2 C O M P L E T E AGORAMODELS OPTIMUS PRIME...
