- Page 1 Display Base B U I L D I N S T R U C T I O N S TRANSFORMERS and HASBRO and all related trademarks and logos are trademarks of Hasbro, Inc. ©2023 Hasbro.
- Page 2 Advice from the experts Please keep ALL unused screws as they may be required in a later stage. Please make sure you don’t mix up the screws. They look quite similar, but the threads do vary slightly. Using the wrong screws may damage the parts. When securing parts together using multiple screws, fit each screw loosely to ensure all the parts are correctly aligned before gently tightening them firmly, but not overtight, in the order in which you placed them.
- Page 3 Assembling the Display Base S T E P 1 TR-BASE-02 Take TR-BASE-02 and insert 4x AA (1.5V) batteries into the battery compartment. Batteries AA S T E P 2 TR-BASE-04 Take TR-BASE-04 and secure it to assembly A using 2x PB 2.3x8 mm screws. Push the cable through the hole as shown in 2b.
- Page 4 Assembling the Display Base S T E P 4 TR-BASE-01 Place TR-BASE-01 onto assembly A. S T E P 5 Connect the cable to TR-BASE-03 then attach TR-BASE-03 the part onto assembly A. AGORAMODELS OPTIMUS PRIME...
-
Page 5: Remote Control
Assembling the Display Base S T E P 6 Take the remote control and remove the two screws from the back. Remote control S T E P 7 Remove the back cover from the remote control. Install a 23A or 27A (12V) battery into the compartment. - Page 6 Assembling the Display Base B A S E C O M P L E T E Slide the switch to “ON” and use the remote control to see your base light up. AGORAMODELS OPTIMUS PRIME...
