Pack 10
B U I L D
I N S T R U C T I O N S
ASSEMBLING THE HIP WHEELS
AT TACHING THE WHEELS TO THE HIPS
ASSEMBLING THE UPPER LEFT LEG
ASSEMBLING THE UPPER RIGHT LEG
ASSEMBLING THE HIPS AND AT TACHING THEM TO THE LEGS
TRANSFORMERS and HASBRO and all related trademarks and logos are trademarks of Hasbro, Inc. ©2023 Hasbro.

Advertisement

loading
Need help?

Need help?

Do you have a question about the OPTIMUS PRIME and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agora Models OPTIMUS PRIME

Summary of Contents for Agora Models OPTIMUS PRIME

  • Page 1 Pack 10 B U I L D I N S T R U C T I O N S ASSEMBLING THE HIP WHEELS AT TACHING THE WHEELS TO THE HIPS ASSEMBLING THE UPPER LEFT LEG ASSEMBLING THE UPPER RIGHT LEG ASSEMBLING THE HIPS AND AT TACHING THEM TO THE LEGS TRANSFORMERS and HASBRO and all related trademarks and logos are trademarks of Hasbro, Inc.
  • Page 2 Always protect the paint finish on components by placing a cutting mat, sheet of white paper or soft cloth on your work surface. Left and Right! When building your Optimus Prime, the left or right hand side refers to each side as viewed by Optimus Prime. Optimus Prime’s left arm is on the viewer’s right.
  • Page 3 TR-10-70 3x6 mm x4 3x6 mm x16 3x10 mm x8 3x8 mm x22 2.6x6 mm x7 nut 3 x4 2x6 mm x11 2.3x6 mm x3 2.6x6 mm x9 2.3x8 mm x9 2.6x8 mm x58 2.3x6 mm x43 AGORAMODELS OPTIMUS PRIME...
  • Page 4 T R A Y 1 T R A Y 1 TR-10-56 TR-10-22 TR-10-49 TR-10-17 TR-10-59 TR-10-19 TR-10-48 TR-10-23 TR-10-04 TR-10-21 TR-10-37 TR-10-26 TR-10-05 TR-10-34 TR-10-58: 20 kg TR-10-54 TR-10-52 TR-10-74: 40 kg TR-10-06 TR-10-35 TR-10-28 TR-10-27 TR-10-51 TR-10-45 TR-10-50 TR-10-55 TR-10-36 AGORAMODELS OPTIMUS PRIME...
  • Page 5 Pack 10 Parts T R A Y 2 TR-10-56 TR-10-49 TR-10-25 TR-10-16 TR-10-59 TR-10-18 TR-10-24 TR-10-43 TR-10-08 TR-10-20 TR-10-37 TR-10-26 TR-10-05 TR-10-34 TR-10-58: 20 kg TR-10-53 TR-10-52 TR-10-74: 40 kg TR-10-06 TR-10-28 TR-10-35 TR-10-27 TR-10-51 TR-10-50 TR-10-44 TR-10-36 TR-10-55 AGORAMODELS OPTIMUS PRIME...
  • Page 6 Pack 10 Parts T R A Y 3 TR-10-75 TR-10-39 TR-10-40 TR-10-01 TR-10-02 TR-10-15 TR-10-46 TR-10-58: 20 kg TR-10-13 TR-10-32 TR-10-11 TR-10-30 TR-10-41 TR-10-12 TR-10-38 TR-10-31 TR-10-07 TR-10-14 TR-10-09 TR-10-03 TR-10-33 TR-10-29 TR-10-47 TR-10-42 TR-10-10 AGORAMODELS OPTIMUS PRIME...
  • Page 7 Part 1 assemblies. PB 2.3x6 TR-10-41 S T E P 3 S T E P 4 Place TR-10-41 onto TR-10-42 – on top of Part 1. Secure parts from the reverse side using 4x PB 2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 8 Attach the asssembly from Step 5 to the assembly A, from Step 4. PWM 2x6 Part 2 S T E P 7 S T E P 8 Secure parts together using 4x PWM 2x6 mm This is assembly now forms Part 2. screws AGORAMODELS OPTIMUS PRIME...
  • Page 9 TR-10-47. TR-10-12 TR-10-11 PB 2.3x6 TR-10-02 S T E P 1 1 S T E P 1 2 Secure parts in place from the reverse side Place TR-10-11 and TR-10-12 onto TR-10-02. using 4x PB2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 10 S T E P 1 5 S T E P 1 6 This assembly now forms Part 3. Push 2x TR-10-57 onto each post on TR-10-50. Repeat with another part TR-10-50 to make 2x Part 4 assemblies. AGORAMODELS OPTIMUS PRIME...
  • Page 11 Place TR-10-48 onto TR-10-45 - on top of Part 4. PB 2.3x6 Part 5 S T E P 1 9 S T E P 2 0 Secure parts from the reverse side using 4x PB This assembly now forms Part 5. 2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 12 Place TR-10-43 on top. it to TR-10-44. PB 2.3x6 Part 6 S T E P 2 3 S T E P 2 4 Secure the parts together using This assembly now forms Part 6. 4x PB 2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 13 S T E P 2 8 Fit TR-10-37 into the tyre TR-10-56. This show the wheel parts correctly fitted together. The rim should fit securely inside the tyre with the inner edge of the tyre tucked under the lip on the rim. AGORAMODELS OPTIMUS PRIME...
  • Page 14 PB 2.6x8 Part 7 S T E P 3 2 S T E P 3 1 This assembly now forms Part 7. Attach TR-10-34 to assembly C and secure in place using 4x PB 2.8x8 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 15 2x PB 2.6x6 mm screws. TR-10-56 TR-10-37 S T E P 3 5 S T E P 3 6 Assemble another wheel by fitting TR-10-37 Check the wheel rim fits snugly and securely into TR-10-56. inside the tyre. AGORAMODELS OPTIMUS PRIME...
  • Page 16 TR-10-34 PB 2.6x8 Part 8 S T E P 3 9 S T E P 4 0 Attach TR-10-34 to assembly C and secure This assembly now forms Part 8. them using 4x PB 2.6x8 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 17 Take part TR-10-38 and align the wheel assemblies (Parts 7 & 8) on either side. Fit the wheels into each corresponding recess as shown. PB 2.3x6 TR-10-52 S T E P 2 Fit 2x parts TR-10-52 over the wheel brackets and secure them using 6x PB 2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 18 PB 2.3x6 Part 6 Part 5 S T E P 4 Take the assemblies labelled Part 5 & Part 6 and fit them to the opposite side of assembly A. Secure using 4x PB 2.3x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 19 Correctly identify the parts above by checking the torque values given on the end of parts TR-10-58 & TR-10-74. Part TR-10-04 is marked with a number ‘1’. Hold TR-10-04 in the orientation shown and fit the widest end of parts 58 and 74 into the recesses. AGORAMODELS OPTIMUS PRIME...
  • Page 20 TR-10-05 M 3x6 TR-10-59 TR-10-69 Part 11 S T E P 3 Attach TR-10-05 to TR-10-59 and secure them using 4 x TR-10-69 washers fitted to 4x M 3x6 mm screws. This now forms assembly Part 11. AGORAMODELS OPTIMUS PRIME...
  • Page 21 Fit assembly Part 11 to assembly Part 10 as shown. M 3x8 TR-10-69 Part 12 S T E P 5 Secure the parts together using 2x TR-10-69 washers fitted to 2x M 3x8 mm screws. This now forms assembly part 12. AGORAMODELS OPTIMUS PRIME...
  • Page 22 Pay close attention to the direction, ensuring the parts indicated with an arrow are facing the same side. Secure the parts together using 2x TR-10-70 washers fitted to 2x M 3x10 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 23 75) to turn the joint through 90 degrees downwards. Then, keeping the rod in place, turn the joint through 90 degrees in a horizontal motion. Now feed the wire through the opening in Part 12 as shown in 7b above. AGORAMODELS OPTIMUS PRIME...
  • Page 24 Fit part TR-10-19 to the joint (A) as shown, securing it place with 4x PB 2.6x8 mm screws. TR-10-70 M 3x8 TR-10-21 S T E P 9 Fit part TR-10-21 to the opposite side of the joint (A), securing it in place with 2x TR-10-70 washers fitted onto 2x M 3x8 screws. AGORAMODELS OPTIMUS PRIME...
  • Page 25 Assembling the Upper Left Leg S T E P 1 0 Fit TR-10-17 over the top. TR-10-17 S T E P 1 1 Secure it using 3x PB 2.6x8 mm screws. PB 2.6x8 AGORAMODELS OPTIMUS PRIME...
  • Page 26 S T E P 1 3 TR-10-23 Take part TR-10-23 and fix part TR-10-36 into the circular recess as shwn. Secure it from the reverse side with a PB 2.6x6 mm TR-10-36 screw. This now forms Part 14. PB 2.6x6 Part 14 AGORAMODELS OPTIMUS PRIME...
  • Page 27 S T E P 1 4 Fit assembly Part 13 to the top of the leg (A), securing it using 4x PB 2.3x8 mm screws. Part 14 S T E P 1 5 Fit assembly Part 14 to the opposite side. AGORAMODELS OPTIMUS PRIME...
  • Page 28 S T E P 1 6 Secure Part 14 from the opposite side using 4x PB 2.6x8 mm screws. PB 2.6x8 TR-10-27 S T E P 1 7 Attach TR-10-27 in the orientation shown and secure using 2x PB 2.6x8 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 29 PWB 2.6x6 TR-10-26 S T E P 1 8 Attach TR-10-26 to the opposite side and secure using 4x PWB 2.6x6 mm screws. TR-10-28 S T E P 1 9 Push TR-10-28 on top, covering the screws. AGORAMODELS OPTIMUS PRIME...
  • Page 30 Part TR-10-08 is marked ‘R1’. TR-10-58 Hold TR-10-08 in the orientation shown and fit the widest end of parts 58 and 74 into the recesses. TR-10-08 AGORAMODELS OPTIMUS PRIME...
  • Page 31 M 3x6 TR-10-05 TR-10-59 TR-10-69 Part 17 S T E P 3 Attach TR-10-05 to TR-10-59 and secure them using 4 x TR-10-69 washers fitted to 4x M 3x6 mm screws. This now forms assembly Part 17. AGORAMODELS OPTIMUS PRIME...
  • Page 32 Fit assembly Part 17 to assembly Part 16 as shown. M 3x8 TR-10-69 Part 18 S T E P 5 Secure the parts together using 2x TR-10-69 washers fitted to 2x M 3x8 mm screws. This now forms assembly part 18. AGORAMODELS OPTIMUS PRIME...
  • Page 33 Pay close attention to the direction, ensuring the parts indicated with an arrow are facing the same side. Secure the parts together using 2x TR-10-70 washers fitted to 2x M 3x10 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 34 (TR-10-75) to turn the joint through 90 degrees downwards. Then, keeping the rod in place, turn the joint through 90 degrees in a horizontal motion (7a). Now feed the wire through the opening in Part 18 as shown in 7b above. AGORAMODELS OPTIMUS PRIME...
  • Page 35 Fit part TR-10-18 to the joint (A) as shown, securing it place with 4x PB 2.6x8 mm screws. TR-10-20 M 3x8 TR-10-70 S T E P 9 Fit part TR-10-20 to the opposite side of the joint (A), securing it in place with 2x TR-10-70 washers fitted onto 2x M 3x8 screws. AGORAMODELS OPTIMUS PRIME...
  • Page 36 Assembling the Upper Right Leg TR-10-16 S T E P 1 0 Fit TR-10-16 over the top. PB 2.6x8 S T E P 1 1 Secure it using 3x PB 2.6x8 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 37 TR-10-24 This now forms Part 20. TR-10-49 Part 20 Part 19 PB 2.3x8 S T E P 1 4 Fit Part 19 to the top of the leg (A), securing it using 4x PB 2.3x8 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 38 Part 20 S T E P 1 5 Fit assembly Part 20 to the opposite side. PB 2.6x8 S T E P 1 6 Secure in place from the opposite side using 4x PB 2.6x8 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 39 Attach TR-10-27 in the orientation shown and secure using 2x PB 2.6x8 mm screws. PWB 2.6x6 TR-10-26 S T E P 1 8 Attach TR-10-26 to the opposite side and secure using 4x PWB 2.6x6 mm screws. AGORAMODELS OPTIMUS PRIME...
  • Page 40 Assembling the Upper Right Leg TR-10-28 S T E P 1 9 Push TR-10-28 on top, covering the screws. Part 21 Part 21 S T E P 2 0 This now forms Part 21. AGORAMODELS OPTIMUS PRIME...
  • Page 41 S T E P 3 TR-10-69 Attach TR-10-09 on top. Thread 2x TR-10-69 TR-10-09 washers onto 2x M 3x8 mm screws, using them to fix the parts together from the reverse side. This now forms Part 23. M 3x8 Part 23 AGORAMODELS OPTIMUS PRIME...
  • Page 42 Place TR-10-33 on top and secure everything together using 2x PWM TR-10-33 2x6 mm screws. TR-10-15 This now forms Part 25. TR-10-03 Part 25 S T E P 6 Attach Part 25 to part Part 24 Part 25 AGORAMODELS OPTIMUS PRIME...
  • Page 43 TR-10-69 M 3x6 Part 15 S T E P 8 Attach the assembly to Part 15 - the Upper left leg. Thread 4x TR-10-69 washers onto 4x M 3x6 mm screws and secure the assembly in place. AGORAMODELS OPTIMUS PRIME...
  • Page 44 S T E P 1 0 Attach the remaining Part 22 to TR-10-40, securing them together using 4x PB2.6x8 mm screws. This now forms Part 27. Note: Take care when fixing these parts together. Too much force may cause them to crack. AGORAMODELS OPTIMUS PRIME...
  • Page 45 S T E P 1 2 Fix the right leg (Part 28) to the left leg (Part 26) using 5x PB 2.6x8 mm screws. Both wires should be routed through the central opening as shown in 12a. This now forms Part 29. AGORAMODELS OPTIMUS PRIME...
  • Page 46 Part 30 S T E P 1 4 Take TR-10-58 and fit into the corresponding recess on TR-10-10 and. Secure the parts together using 2x TR-10-69 washers and 2x M 3x8 mm screws. This now forms Part 30. AGORAMODELS OPTIMUS PRIME...
  • Page 47 PM 3x6 S T E P 1 6 Attach part 9 to Part 31 and secure using 4x PM 3x6 mm screws. Check that the wires continue to be routed Part 9 through part 9. Part 31 AGORAMODELS OPTIMUS PRIME...
  • Page 48 Assembling the Hips and Attaching Them to the Legs S T E P 1 For the next stage of the build, the hip position must be rotated from the position shown in 17 to the position shown in 17a. AGORAMODELS OPTIMUS PRIME...
  • Page 49 S T E P 1 8 Attach TR-10-29 and TR- 10-30 to the assembly as shown. These parts are attached at an angle, in the orientation shown Secure them in place TR-10-30 TR-10-29 using 4x PB 2.3x6 mm screws. PB 2.3x6 AGORAMODELS OPTIMUS PRIME...
  • Page 50 Drive 4x PB 2.3x6 mm screws into the holes, shown. You may need to lift the parts indicated by arrows to access the screw holes. PB 2.3x6 P A C K 1 0 C O M P L E T E AGORAMODELS OPTIMUS PRIME...
