Mini-ITX SBC supports 14nm LGA1151 Intel® 8th Generation Core™
i7/i5/i3, Celeron® and Pentium® processor, DDR4, dual independent
displays, dual GbE LAN, M.2, SATA 6Gb/s, HD Audio and RoHS
Quick Installation Guide
Package List
KINO-DH310 package includes the following items:
1 x KINO-DH130 single board computer
1 x I/O Shielding
1 x SATA cable
1 x QIG
©2020 Copyright by IEI Integration Corp.
KINO-DH310
Version 1.0
March 26, 2020
All rights reserved.
1
Advertisement
Related Manuals for IEI Technology KINO-DH310
Summary of Contents for IEI Technology KINO-DH310
- Page 1 GbE LAN, M.2, SATA 6Gb/s, HD Audio and RoHS KINO-DH310 Quick Installation Guide Version 1.0 March 26, 2020 Package List KINO-DH310 package includes the following items: 1 x KINO-DH130 single board computer 1 x I/O Shielding 1 x SATA cable ...
- Page 2 All manuals and user guides at all-guides.com Specifications CPU: LGA1151 socket supports 8th generation Intel® Core™ i7/i5/i3, Pentium® or Celeron® processor (35W/65W) System Chipset: Intel® H310 Memory: Two 260-pin 2666/2400 MHz dual-channel DDR4 SDRAM un-buffered SO-DIMMs supporting up to 64GB ...
- Page 3 All manuals and user guides at all-guides.com Realtek ALC662 HD codec 2 x Audio jack (Lin-out, Mic-in) 1 x Front audio (2x5 pin) Front Panel: 1 x Front Panel (1x10 pin, power LED, HDD LED, power button, reset button) ...
- Page 4 IEI Resource Download Center KINO-DH310 are available on IEI https://download.ieiworld.com Resource Download Center. Type KINO-DH310 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to view its content.
- Page 5 All manuals and user guides at all-guides.com Jumpers setting and connectors LABEL FUNCTION J_ATX_AT1 AT/ATX Power Mode Setting J_CMOS1 Clear CMOS Button USB SW1, USB SW2 USB Power Setting J_FLASH1 Flash Descriptor Security Override F_PANEL1 PWR & RST Buttons and Indicators HDMI Port B (Up) &...
- Page 6 All manuals and user guides at all-guides.com COM4 Internal RS-422/485 Serial Port Connector TPM1 Trusted Platform Module Connector J_ATX_AT1: AT/ATX Power Mode Setting PIN NO. DESCRIPTION Short 1 - 2 ATX Power Mode (default) Short 2 - 3 AT Power Mode J_CMOS1: Clear CMOS Button PIN NO.
- Page 7 All manuals and user guides at all-guides.com F_PANEL1: PWR & RST Buttons and Indicators DESCRIPTION DESCRIPTION PWRLED PWRBTSW# PWRLED +V5S RESET+ RESET HDD_LED- HDMI1: HDMI Port B (Up) & HDMI Port C (Down) Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS_C_DATA2P TMDS_B_DATA2P TMDS_C_DATA2N...
- Page 8 All manuals and user guides at all-guides.com DP1: Internal Display Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION AUXP LANE1N AUXN LANE1P LANE2P LANE3N LANE2N LANE3P LANE0P AUX_CTRL_DET_D LANE0N +3.3V LAN1_USB1: Ethernet and USB 3.2 Gen 1 Connectors USB1: External USB 3.2 Gen 1 Connectors PIN NO.
-
Page 9: Table Of Contents
All manuals and user guides at all-guides.com LAN2_USB2: Ethernet and USB 3.2 Gen 1 Connectors USB2: External USB 3.2 Gen 1 Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ LAN2: RJ-45 LAN connector... - Page 10 All manuals and user guides at all-guides.com COM3: Internal RS-232 Serial Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION COM1: External RS-232 Serial Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION AUDIO_CV1 : Audio Line-In/Out MIC Connector PIN NO. DESCRIPTION Line_Out Connect this port to headphone or speaker (Green)
-
Page 11: Gnd
All manuals and user guides at all-guides.com SATA1, SATA2: SATA 6Gb/s Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX- SATA_TX+ SATA RX+ SATA_TX- M2_M1: M.2 M-key Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V PERn1 PERp1 PETn1 PETp1... -
Page 12: Description Vcc
All manuals and user guides at all-guides.com CLKN CLKP PEDET 3.3V 3.3V 3.3V CPU_FAN1: CPU Fan Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FANIO SYS_FAN1: System Fan Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FANIO DIO1: Digital Input / Output Connector PIN NO. -
Page 13: Vcc
All manuals and user guides at all-guides.com PWR1: Power Connector (12V, Power Adapter) PIN NO. DESCRIPTION PIN NO. DESCRIPTION CN2: Internal Power Connector (12V) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB1: SMBus Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_DATA SMB_CLK I2C1: I C Connector (to EC) - Page 14 All manuals and user guides at all-guides.com M2_A1: M.2 A-key Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V USB2_DP +3.3V USB2_DN PETP0 PETN0 PERP0 PERN0 PCIE_CLK+ PCIE_CLK- PLT_RST PCIE_WAKE W_DIS...
- Page 15 All manuals and user guides at all-guides.com CLK_REQ +3.3V +3.3V +3.3V CN1: EC Debug Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_EPP_STB# EC_EPP_BUSY EC_EPP_PD0 EC_EPP_KSI5 EC_EPP_PD1 EC_EPP_KSI4 EC_EPP_PD2 EC_EPP_AFD# EC_EPP_PD3 EC_EPP_PD4 EC_EPP_INIT# EC_EPP_PD5 EC_EPP_SLIN# EC_EPP_PD6 EC_EPP_PD7 SATA_PWR1, SATA_PWR2: SATA Power Connectors PIN NO.
- Page 16 All manuals and user guides at all-guides.com TPM1: Trusted Platform Module Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCLK LFRAME# LRERST# LAD3 LAD2 +3.3V LAD1 LAD0 SB3V SERIRQ GLKRUN# LPCPD# LDRQ#...
- Page 17 All manuals and user guides at all-guides.com Board Layout: Jumper and Connector Locations (Unit: mm)
