IEI Technology KINO-EHL Series User Manual

Mini-itx sbc supports intel celeron j6412 on-board soc with 8gb lpddr4x memory on board default, with hdmi, dp, idpm, 2.5gbe lan, m.2, pcie x4 slot, sata 6gb/s, com, usb 3.2 gen 2, iaudio, 0c-60c and rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KINO-EHL-J6412 Mini-ITX SBC
MODEL:
KINO-EHL Series
Mini-ITX SBC Supports Intel® Celeron® J6412 on-board SoC
with 8GB LPDDR4x memory on board default, with HDMI, DP,
iDPM, 2.5GbE LAN, M.2, PCIe x4 Slot, SATA 6Gb/s, COM, USB
3.2 Gen 2, iAUDIO, 0° C~60° C and RoHS
User Manual
Page i
Rev. 1.00 – December 14, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINO-EHL Series and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology KINO-EHL Series

Summary of Contents for IEI Technology KINO-EHL Series

  • Page 1 KINO-EHL-J6412 Mini-ITX SBC MODEL: KINO-EHL Series Mini-ITX SBC Supports Intel® Celeron® J6412 on-board SoC with 8GB LPDDR4x memory on board default, with HDMI, DP, iDPM, 2.5GbE LAN, M.2, PCIe x4 Slot, SATA 6Gb/s, COM, USB 3.2 Gen 2, iAUDIO, 0° C~60° C and RoHS...
  • Page 2 KINO-EHL-J6412 Mini-ITX SBC Revision Date Version Changes December 14, 2022 1.00 Initial release Page ii...
  • Page 3 KINO-EHL-J6412 Mini-ITX SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 KINO-EHL-J6412 Mini-ITX SBC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.

  • Page 5: Table Of Contents

    KINO-EHL-J6412 Mini-ITX SBC Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 B ........................3 ENEFITS 1.3 F ........................3 EATURES 1.4 C ......................4 ONNECTORS 1.5 D ........................5 IMENSIONS 1.6 D .........................6 1.7 T ..................6 ECHNICAL PECIFICATIONS 2 PACKING LIST ......................9 2.1 A ..................10 STATIC...
  • Page 6 KINO-EHL-J6412 Mini-ITX SBC 3.2.10 M.2 Slot, A-key ....................25 3.2.11 M.2 Slot, B-key ....................27 3.2.12 IDPM Slot .......................29 3.2.13 Power Button ....................31 3.2.14 Power Connector ....................32 3.2.15 SATA 6Gb/s Drive Connector .................33 3.2.16 SATA Power Connector...................34 3.2.17 Serial Port Connector, RS-422/485..............35 3.2.18 SMBus Connector ...................36 3.2.19 I2C Connector ....................37 3.2.20 Flash SPI ROM Connector ................38...
  • Page 7 KINO-EHL-J6412 Mini-ITX SBC 4.5.1 SATA Drive Connection ..................60 4.5.2 USB Cable Connection ..................61 4.6 D ....................62 RIVER OWNLOAD 5 BIOS ..........................65 5.1 I ......................66 NTRODUCTION 5.1.1 Starting Setup ....................66 5.1.2 Using Setup .......................67 5.1.2.1 Keyboard Navigation .................67 5.1.2.2 Touch Navigation ..................68 5.1.3 Getting Help ......................69 5.1.4 Unable to Reboot after Configuration Changes ..........69 5.1.5 BIOS Menu Bar ....................69...
  • Page 8 KINO-EHL-J6412 Mini-ITX SBC 5.4.2.1 PCI Express Configuration ..............103 5.4.2.1.1 PCIe Root Port Setting ................103 5.4.2.1.2 M2_B_KEY Slot ................105 5.4.2.1.3 M2_A_KEY Slot................106 5.4.2.2 SATA Configuration .................108 5.4.2.3 USB Configuration ..................109 5.4.2.4 HD Audio Configuration................110 5.5 S ........................ 111 ECURITY 5.6 B ........................
  • Page 9 KINO-EHL-J6412 Mini-ITX SBC List of Figures Figure 1-1: KINO-EHL-J6412 ....................2 Figure 1-2: Connectors ......................4 Figure 1-3: KINO-EHL-J6412 Series Main Dimensions (mm) ..........5 Figure 1-4: Data Flow Diagram....................6 Figure 3-1: Connectors and Jumpers ................. 14 Figure 3-2: Audio Connector Location ................17 Figure 3-3: Battery Connector Location ................
  • Page 10 KINO-EHL-J6412 Mini-ITX SBC Figure 3-27: USB 2.0 Connector Locations ................. 44 Figure 3-28: External Peripheral Interface Connector ............45 Figure 3-29: Ethernet Connector..................46 Figure 3-30: Ethernet Connector..................47 Figure 3-31: Serial Port Pinouts ..................48 Figure 3-32: Power Connector (4-pin DIN) ................49 Figure 3-33: DP Connector Pinout Locations..............
  • Page 11 KINO-EHL-J6412 Mini-ITX SBC List of Tables Table 1-1: KINO-EHL-J6412 Series Specifications ..............8 Table 2-1: Packing List ....................... 11 Table 3-1: Peripheral Interface Connectors................. 16 Table 3-2: Rear Panel Connectors ..................16 Table 3-3: Audio Connector Pinouts ................... 17 Table 3-4: Battery Connector Pinouts ................. 18 Table 3-5: Buzzer Connector Pinouts .................
  • Page 12 KINO-EHL-J6412 Mini-ITX SBC Table 3-29: USB 2.0 Port Pinouts ..................46 Table 3-30: LAN1 Ethernet Connector Pinouts ..............47 Table 3-31: Connector LEDs ....................47 Table 3-32: USB 3.2 Gen 2 Port Pinouts ................47 Table 3-33: Serial Port Pinouts ................... 48 Table 3-34: HDMI and DP Connector Pinouts ..............
  • Page 13 KINO-EHL-J6412 Mini-ITX SBC BIOS Menus BIOS Menu 1: Main (1/2)...................... 70 BIOS Menu 2: Main (2/2)...................... 70 BIOS Menu 3: Advanced ..................... 73 BIOS Menu 4: CPU Configuration (1/3) ................74 BIOS Menu 5: CPU Configuration (2/3) ................75 BIOS Menu 6: CPU Configuration (3/3) ................75 BIOS Menu 7: PCH-FW Configuration .................
  • Page 14 KINO-EHL-J6412 Mini-ITX SBC BIOS Menu 31: Security ....................111 BIOS Menu 32: Boot......................112 BIOS Menu 33: Save & Exit ....................114 Page xiv...

  • Page 15: Introduction

    KINO-EHL-J6412 Mini-ITX SBC Chapter Introduction Page 1...

  • Page 16: Ntroduction

    KINO-EHL-J6412 Mini-ITX SBC 1.1 Introduction Figure 1-1: KINO-EHL-J6412 The KINO-EHL-J6412 is a Mini-ITX form factor single bard computer. It has an on-board 10nm Intel® Celeron® processor, and supports on-board 8GB 3200 MHz LPDDR4X (system max. 16GB). The KINO-EHL-J6412 series includes one DP port and one HDMI port for dual independent display.

  • Page 17: Benefits

    KINO-EHL-J6412 Mini-ITX SBC 1.2 Benefits The KINO-EHL-J6412 motherboard benefits include:  Powerful graphics support multi-display  Staying connected with wired LAN connections  Speedy running of multiple programs and applications 1.3 Features The KINO-EHL-J6412 motherboard features are listed below:  Mini-ITX form factor ...

  • Page 18: Connectors

    KINO-EHL-J6412 Mini-ITX SBC 1.4 Connectors The connectors on the KINO-EHL-J6412 are shown in the figure below. Figure 1-2: Connectors Page 4...

  • Page 19: Dimensions

    KINO-EHL-J6412 Mini-ITX SBC 1.5 Dimensions The main dimensions of the KINO-EHL-J6412 are shown in the diagram below. Figure 1-3: KINO-EHL-J6412 Series Main Dimensions (mm) Page 5...

  • Page 20: Data Flow

    KINO-EHL-J6412 Mini-ITX SBC 1.6 Data Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other 852H components installed on the motherboard. Figure 1-4: Data Flow Diagram 1.7 Technical Specifications The KINO-EHL-J6412 technical specifications are listed below.
  • Page 21 KINO-EHL-J6412 Mini-ITX SBC Specification/Model KINO-EHL-J6412 Series Memory On-board 8GB 3200 MHz LPDDR4X (system max. 16GB) Integrated Graphics Intel® UHD Graphics for 10th Gen Intel® Processors Audio 1 x iAUDIO (2x5 pin), supporting IEI AC-KIT-888S kit BIOS UEFI BIOS Ethernet Controllers 2 x PCIe 2.5GbE with Intel®...

  • Page 22: Table 1-1: Kino-Ehl-J6412 Series Specifications

    KINO-EHL-J6412 Mini-ITX SBC Specification/Model KINO-EHL-J6412 Series USB Ports Two external USB 3.2 Gen 2 (10Gb/s) ports Two external USB 2.0 ports Four USB 2.0 ports by two 8-pin headers Serial ATA One SATA 6Gb/s connector with one SATA power connector SMBus Supported by one 4-pin wafer connector Environmental and Power Specifications...

  • Page 23: Packing List

    KINO-EHL-J6412 Mini-ITX SBC Chapter Packing List Page 9...

  • Page 24: Anti-Static Precautions

    KINO-EHL-J6412 Mini-ITX SBC 2.1 Anti-static Precautions WARNING! Static electricity can destroy certain electronics. Make sure to follow the ESD precautions to prevent damage to the product, and injury to the user. Make sure to adhere to the following guidelines:  Wear an anti-static wristband: Wearing an anti-static wristband can prevent electrostatic discharge.

  • Page 25: Packing List

    KINO-EHL-J6412 Mini-ITX SBC 2.3 Packing List NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the KINO-EHL-J6412 series was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com 326H378H...

  • Page 26: Optional Items

    KINO-EHL-J6412 Mini-ITX SBC 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image USB cable, 300mm (P/N : CB-USB02A-RS) RS-422/485 cable, 200mm (P/N: 32205-003800-300-RS) IEI audio module (P/N: AC-KIT-888S-R10) eDP to eDP converter board (for IEI iDPM connector) (P/N: iDPM-eDP-R10) eDP to LVDS converter board (for IEI iDPM connector) (P/N: iDPM-LVDS-R10)

  • Page 27: Connectors

    KINO-EHL-J6412 Mini-ITX SBC Chapter Connectors Page 13...

  • Page 28: Peripheral Interface Connectors

    KINO-EHL-J6412 Mini-ITX SBC 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 KINO-EHL-J6412 Layout The figures below show all the connectors and jumpers. Figure 3-1: Connectors and Jumpers 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label...
  • Page 29 KINO-EHL-J6412 Mini-ITX SBC Connector Type Label Digital I/O connector 14-pin header DIO1 Fan connector (CPU) 4-pin wafer CPU_FAN1 Fan connector (system) 3-pin wafer SYS_FAN2 Front panel connector 14-pin header F_PANEL1 Memory SDRAM(s) On-board LPDDR4X U242, U243, U244, U245 microSD card slot microSD slot PCIe x4 slot (x1 signal) PCIe x4 slot...

  • Page 30: External Interface Panel Connectors

    KINO-EHL-J6412 Mini-ITX SBC Connector Type Label Flash Setting Jumper 3-pin header J_FLASH1 USB 2.0 connectors 8-pin header JUSB3, JUSB4 Clear CMOS Button Press button J_CMOS2 Table 3-1: Peripheral Interface Connectors 3.1.3 External Interface Panel Connectors The table below lists the connectors on the external I/O panel. Connector Type Label...

  • Page 31: Battery Connector

    KINO-EHL-J6412 Mini-ITX SBC Figure 3-2: Audio Connector Location Description Description HDA_SYNC HDA_CLK HDA_SDOUT HDA_SPKR HDA_SDIN HDA_RST# +12V Table 3-3: Audio Connector Pinouts 3.2.2 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.

  • Page 32: Figure 3-3: Battery Connector Location

    KINO-EHL-J6412 Mini-ITX SBC CN Label: BAT1 CN Type: 2-pin wafer, p=1.25 mm CN Location: See Figure 3-3 CN Pinouts: See Table 3-4 A system battery is placed in the battery holder. The battery provides power to the system clock to retain the time when power is turned off. NOTE: It is recommended to attach the RTC battery onto the system chassis in which the KINO-EHL-J6412 is installed.

  • Page 33: Buzzer Intrusion Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.3 Buzzer Intrusion Connector CN Label: CN Type: 2-pin header, p=1.25 mm CN Location: Figure 3-4 787H CN Pinouts: See Table 3-5 The buzzer connector is connected to a buzzer. Figure 3-4: Buzzer Connector Location Description PC_BEEP Table 3-5: Buzzer Connector Pinouts Page 19...

  • Page 34: Digital I/O Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.4 Digital I/O Connector CN Label: DIO1 CN Type: 14-pin header, p=2.00 mm CN Location: See Figure 3-5 CN Pinouts: See Table 3-6 The digital I/O connector provides programmable input and output for external devices. Figure 3-5: Digital I/O Connector Location PIN NO.

  • Page 35: Fan Connector (Cpu)

    KINO-EHL-J6412 Mini-ITX SBC 3.2.5 Fan Connector (CPU) CN Label: CPU_FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location: See Figure 3-6 CN Pinouts: See Table 3-7 The fan connector attaches to a CPU cooling fan. Figure 3-6: CPU Fan Connector Location PIN NO.

  • Page 36: Fan Connector (System)

    KINO-EHL-J6412 Mini-ITX SBC 3.2.6 Fan Connector (System) CN Label: SYS_FAN2 CN Type: 3-pin wafer, p=2.54 mm CN Location: See Figure 3-7 CN Pinouts: See Table 3-8 Each fan connector attaches to a system cooling fan. Figure 3-7: System Fan Connector Location PIN NO.

  • Page 37: Front Panel Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.7 Front Panel Connector CN Label: F_PANEL1 CN Type: 14-pin header, p=2.54 mm CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 38: On-Board Lpddr4 (S)

    KINO-EHL-J6412 Mini-ITX SBC 3.2.8 On-board LPDDR4 (s) CN Label: U242, U243, U244, U245 CN Type: On-board LPDDR4X CN Location: Figure 3-9 791H Figure 3-9: On-board LPDDR4 Locations 3.2.9 PCIe x4 Slot CN Label: PCIEX4_1 CN Type: PCIe x4 slot CN Location: See Figure 3-10 The PCIe x4 interface provides x1 signal for PCIe expansion cards.

  • Page 39: Slot, A-Key

    KINO-EHL-J6412 Mini-ITX SBC 3.2.10 M.2 Slot, A-key CN Label: M2_A_KEY CN Type: M.2 A-key slot CN Location: Figure 3-11 791H CN Pinouts: See Table 3-10 The M.2 slot is keyed in the A position and accepts 2230 size of M.2 modules. The M.2 slot supports PCIe x1 and USB 2.0 signals.

  • Page 40: Table 3-10: M.2 A-Key Slot Pinouts

    KINO-EHL-J6412 Mini-ITX SBC Description Description PCIE_TX4+ PCIE_TX4- PCIE_RX4+ PCIE_RX4- CLK_M2_A+ CLK_M2_A- BTWIFI_SUS_CLK WLAN_PERST# +V3.3A_WLAN +V3.3A_WLAN +V3.3A_WLAN PEWAKE# +V3.3A +V3.3A Table 3-10: M.2 A-key Slot Pinouts Page 26...

  • Page 41: Slot, B-Key

    KINO-EHL-J6412 Mini-ITX SBC 3.2.11 M.2 Slot, B-key CN Label: M2_B_KEY CN Type: M.2 B-key slot CN Location: See Figure 3-12 CN Pinouts: See Table 3-11 The M.2 slot is keyed in the B position and accepts 3052/2242 size of M.2 modules. The M.2 slot supports PCIe x2 and USB 2.0 signals.

  • Page 42: Table 3-11: M.2 B-Key Slot Pinouts

    KINO-EHL-J6412 Mini-ITX SBC Module Key Module Key Module Key PSE_I2S1_SCLK WWAN_CONFIG0 PSE_I2S1_TXD PCIE_WAKE# PSE_I2S1_RXD GNSS_DISABLE_ SAR_DPR_WWAN PCIE_RXN7 WWAN_UIM_RST PCIE_RXP7 WWAN_UIM_CLK WWAN_UIM_DAT PCIE_TXN7 UIM_PWR PCIE_TXP7 SSD_DEVSLP PCIE_RXN6 PCIE_RXP6 PCIE_TXN6 PCIE_TXP6 WWAN_PERST# CLK_M2_B_N WWAN_WAKE# CLK_M2_B_P WWAN_SIM1_DET WWAN_RST WWAN_SUSCLK DET_OS-PCIE/ +3.3V GND-SATA +3.3V +3.3V WWAN_CONFIG2 Table 3-11: M.2 B-key Slot Pinouts...

  • Page 43: Idpm Slot

    KINO-EHL-J6412 Mini-ITX SBC 3.2.12 IDPM Slot CN Label: IDPM CN Type: M.2 B-key slot CN Location: See Figure 3-13 CN Pinouts: See Table 3-12 The iDPM slot only use for IEI eDP/LVDS/VGA module Figure 3-13: IDPM Slot Location IDPM: IEI IDPM Slot (for IEI eDP/LVDS/VGA Module) PIN NO.

  • Page 44: Table 3-12: Idpm Connector Pinouts

    KINO-EHL-J6412 Mini-ITX SBC DISPLAY_DETECT_P +3.3VS IN23 +3.3VS EDP_TX3_DN +12VS EDP_TX3_DP +12VS +12VS EDP_TX2_DN +12VS EDP_TX2_DP SMB_CLK EDP_TX1_DN SMB_DATA EDP_TX1_DP EC_BKLT_CTRL EDP_TX0_DN EDP1_BKLT_CTRL EDP_TX0_DP EDP1_BKLT_EN EDP1_VDD_EN # EDP_AUX_DN EDP_HPD_R EDP_AUX_DP BUF_PLT_RST# LVDS_EN +V5S +V5S +V5S +V5S +12VA +12VA +12VA +12VA Table 3-12: IDPM Connector Pinouts Page 30...

  • Page 45: Power Button

    KINO-EHL-J6412 Mini-ITX SBC 3.2.13 Power Button CN Label: PWR_SW1 CN Type: Push button CN Location: See Figure 3-14 The on-board power button controls system power. Figure 3-14: Power Button Location Page 31...

  • Page 46: Power Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.14 Power Connector CN Label: CN Type: 4-pin connector, p=4.2 mm CN Location: See Figure 3-15 CN Pinouts: See Table 3-13 The power input connector provides power to the system. Figure 3-15: Power Connector Location Description Description +12 V +12 V Table 3-13: Power Connector Pinouts...

  • Page 47: Sata 6Gb/S Drive Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.15 SATA 6Gb/s Drive Connector CN Label: S_ATA1 CN Type: 7-pin SATA drive connectors CN Location: See Figure 3-16 CN Pinouts: See Table 3-14 The SATA drive connector can be connected to SATA drives. Figure 3-16: SATA 6Gb/s Drive Connector Location Description SATA_TX+ SATA_TX-...

  • Page 48: Sata Power Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.16 SATA Power Connector CN Label: SATA_PWR1 CN Type: 2-pin wafer, p=2.00 mm CN Location: See Figure 3-17 CN Pinouts: See Table 3-15 Use the SATA Power Connector to connect to SATA device power connections. Figure 3-17: SATA Power Connector Location Description +5 V Table 3-15: SATA Power Connector Pinouts...

  • Page 49: Serial Port Connector, Rs-422/485

    KINO-EHL-J6412 Mini-ITX SBC 3.2.17 Serial Port Connector, RS-422/485 CN Label: COM3, COM4, COM5, COM6 CN Type: 4-pin wafer, p=2.00 mm CN Location: See Figure 3-18 CN Pinouts: See Table 3-16 Used for RS-422/485 communications. Figure 3-18: RS-422/485 Connector Location PIN NO. DESCRIPTION Table 3-16: RS-422/485 Connector Pinouts Page 35...

  • Page 50: Smbus Connector

    KINO-EHL-J6412 Mini-ITX SBC Use the optional RS-422/485 cable to connect to a serial device. The pinouts of the D-sub 9 connector are listed below. RS-422 Pinouts RS-485 Pinouts Table 3-17: RS-422/485 Pinouts of D-sub 9 Connector 3.2.18 SMBus Connector CN Label: SMB1 CN Type: 4-pin wafer, p=1.25 mm...

  • Page 51: I2C Connector

    KINO-EHL-J6412 Mini-ITX SBC DESCRIPTION SMB_DATA SMB_CLK +5 V Table 3-18: SMBus Connector Pinouts 3.2.19 I2C Connector CN Label: I2C1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 3-20 CN Pinouts: See Table 3-19 The I C connector is used to connect I C-bus devices to the motherboard.

  • Page 52: Flash Spi Rom Connector

    KINO-EHL-J6412 Mini-ITX SBC Description I2C_DATA I2C_CLK Table 3-19: I2C Connector Pinouts 3.2.20 Flash SPI ROM Connector CN Label: JBIOS1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-21 CN Pinouts: See Table 3-20 The Flash SPI ROM connector is used to flash t he SPI ROM. Figure 3-21: Flash SPI ROM Connector Location Page 38...

  • Page 53: Flash Ec Rom Connector

    KINO-EHL-J6412 Mini-ITX SBC PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CLK SPI_CS# SPI_SI SPI_SO Table 3-20: Flash SPI ROM Connector Pinouts 3.2.21 Flash EC ROM Connector CN Label: JEC2 CN Type: 8-pin header, p=1.27 mm CN Location: See Figure 3-22 CN Pinouts: See Table 3-21 The Flash EC ROM connector is used to flash the EC ROM.

  • Page 54: Bios Debug Connector

    KINO-EHL-J6412 Mini-ITX SBC EC_DET_FLASH SPI_CLK SPI_SI Table 3-21: Flash EC ROM Connector Pinouts 3.2.22 BIOS Debug Connector CN Label: J_CONSOLE1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-23 CN Pinouts: See Table 3-22 Figure 3-23: BIOS Debug Connector Location PIN NO.

  • Page 55: Ec Debug Connector

    KINO-EHL-J6412 Mini-ITX SBC 3.2.23 EC Debug Connector CN Label: DEBUG_SPI1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-24 CN Pinouts: See Table 3-23 Figure 3-24: EC Debug Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION EDICLK EDICS EDIDI EDIDO Table 3-23: EC Debug Connector Pinouts...

  • Page 56: Ec Uart Debug Port Connector

    KINO-EHL-J6412 Mini-ITX SBC CN Pinouts: See Table 3-24 Figure 3-25: EC SMBus Debug Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V5A SMDAT0_EC SMCLK0_EC PLT_RST_N Table 3-24: EC SMBus Debug Port Connector Pinouts 3.2.25 EC UART Debug Port Connector CN Label: EC_UART1 CN Type:...

  • Page 57: Usb 2.0 Connectors

    KINO-EHL-J6412 Mini-ITX SBC Figure 3-26: EC UART Debug Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION UART_TX UART_RX +3.3V Table 3-25: EC UART Debug Port Connector Pinouts 3.2.26 USB 2.0 Connectors CN Label: JUSB3, JUSB4 CN Type: 8-pin header, p=2.00 mm CN Location: See Figure 3-27 CN Pinouts:...

  • Page 58: Figure 3-27: Usb 2.0 Connector Locations

    KINO-EHL-J6412 Mini-ITX SBC Figure 3-27: USB 2.0 Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA+ USB_DATA+ USB_DATA- Table 3-26: USB 2.0 Connector Pinouts Page 44...

  • Page 59: External Peripheral Interface Connector Panel

    KINO-EHL-J6412 Mini-ITX SBC 3.3 External Peripheral Interface Connector Panel The figure below shows the external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following: Figure 3-28: External Peripheral Interface Connector 3.3.1 Ethernet and USB 2.0 Combo Connector CN Label: J_LAN2_USB2 CN Type:...

  • Page 60: Ethernet And Usb 3.2 Gen 2 Combo Connector

    KINO-EHL-J6412 Mini-ITX SBC Figure 3-29: Ethernet Connector Description Description on: linked off: 100 Mb/s blinking: data is being sent/received green: 1000 Mb/s orange: 2500 Mb/s Table 3-28: Connector LEDs The USB 2.0 connector can be connected to a USB 2.0 device. Description Description USB_DATA-...

  • Page 61: Figure 3-30: Ethernet Connector

    KINO-EHL-J6412 Mini-ITX SBC Description Description LAN1_MDI0N LAN1_MDI2N LAN1_MDI1P LAN1_MDI3P LAN1_MDI1N LAN1_MDI3N Table 3-30: LAN1 Ethernet Connector Pinouts Figure 3-30: Ethernet Connector Description Description on: linked off: 100 Mb/s blinking: data is being sent/received green: 1000 Mb/s orange: 2500 Mb/s Table 3-31: Connector LEDs The USB 3.2 Gen 2 (10Gb/s) connector can be connected to a USB device.

  • Page 62: Serial Port Connectors (Com1 And Com2)

    KINO-EHL-J6412 Mini-ITX SBC 3.3.3 Serial Port Connectors (COM1 and COM2) CN Label: COM1 CN Type: D-sub 9 CN Location: See Figure 3-28 CN Pinouts: See Table 3-33 and Figure 3-31 The serial port connects to a RS-232 serial communications device. Description Description DCD1...

  • Page 63: Hdmi And Dp Connector

    KINO-EHL-J6412 Mini-ITX SBC CN Pinouts: See Figure 3-32 The connector supports the 12V power adapter. Figure 3-32: Power Connector (4-pin DIN) 3.3.5 HDMI and DP Connector CN Label: HDMI_DP1 CN Type: HDMI and DP connector CN Location: See Figure 3-28 CN Pinouts: See Table 3-34 The HDMI connector can connect to HDMI devices, The DP connector can connect to...

  • Page 64: Figure 3-33: Dp Connector Pinout Locations

    KINO-EHL-J6412 Mini-ITX SBC PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI2_DATA2 HDMI2_DATA2# HDMI2_DATA1 HDMI2_DATA1# HDMI2_DATA0 HDMI2_DATA0# HDMI2_CLK HDMI2_CLK# HDMI2_SCL HDM2I_SDA HDMI2_HPD Table 3-34: HDMI and DP Connector Pinouts Figure 3-33: DP Connector Pinout Locations Figure 3-34: HDMI Connector Pinout Locations Page 50...

  • Page 65: Installation

    KINO-EHL-J6412 Mini-ITX SBC Chapter Installation Page 51...

  • Page 66: Anti-Static Precautions

    KINO-EHL-J6412 Mini-ITX SBC 4.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the KINO-EHL-J6412 result permanent damage KINO-EHL-J6412 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-EHL-J6412. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the KINO-EHL-J6412 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 67 KINO-EHL-J6412 Mini-ITX SBC WARNING: The installation instructions described in this manual should be carefully followed in order to prevent damage to the components and injury to the user. Before and during the installation please DO the following:  Read the user manual: The user manual provides a complete description of the KINO-EHL-J6412 installation instructions and configuration options.

  • Page 68: Module Installation

    KINO-EHL-J6412 Mini-ITX SBC 4.3 M.2 Module Installation The KINO-EHL provide two ways to install the M.2 expansion card. One is using screw, and the other is using the retainer. Please follow the steps below. Mode One: Using screw Step 1: Locate the M.2 module slot.

  • Page 69: Figure 4-3: Press The Retainer

    KINO-EHL-J6412 Mini-ITX SBC Mode Two: Using the Retainer Step 1: Press the retainer down as shown below. (See Figure 4-3) Figure 4-3: Press the Retainer Step 2: Line up the notch on the M.2 module with the notch on the slot. Slide the M.2 module into the socket at an angle of about 20º...

  • Page 70: Figure 4-5: Securing The M.2 Module

    KINO-EHL-J6412 Mini-ITX SBC Step 4: Press the M.2 module down until it is secured into place by the retainer. (See Figure 4-5) 20° Figure 4-5: Securing the M.2 Module Step 5: If you want to remove the M.2 module, you should press the retainer down as described in Step 1 to release the M.2 module..

  • Page 71: System Configuration

    KINO-EHL-J6412 Mini-ITX SBC 4.4 System Configuration The KINO-EHL-J6412 is a jumperless single board computer. The system configuration is controlled by buttons and switches. The system configuration must be performed before installation. 4.4.1 AT/ATX Power Mode Setting The AT and ATX power mode selection is made through the AT/ATX power mode switch which is shown in Figure 4-6.

  • Page 72: Dnx Mode Setting Jumper

    KINO-EHL-J6412 Mini-ITX SBC 4.4.2 DNX Mode Setting Jumper Setting DESCRIPTION Open Normal (default) Short Enable DNX Boot 4.4.3 Clear CMOS Button To reset the BIOS, remove the on-board battery and press the clear CMOS button for three seconds or more. The clear CMOS button location is shown in Figure 4-7. Figure 4-7: Clear CMOS Button Location Page 58...

  • Page 73: Flash Descriptor Security Override

    KINO-EHL-J6412 Mini-ITX SBC 4.4.4 Flash Descriptor Security Override The Flash Descriptor Security Override jumper (J_FLASH1) specifies whether to override the flash descriptor. Setting Description Short 1-2 Disable (default) Short 2-3 Enable Table 4-1: Flash Descriptor Security Override Jumper Settings Figure 4-8: Flash Descriptor Security Override Jumper Location 4.4.5 BIOS1/BIOS2 Select Jumper Use the BIOS1/BIOS2 Select jumper (J_BIOS1) to select BIOS1 or BIOS2.

  • Page 74: Internal Peripheral Device Connections

    KINO-EHL-J6412 Mini-ITX SBC Figure 4-9: BIOS1/BIOS2 Select Jumper Location 4.5 Internal Peripheral Device Connections This section outlines the installation of peripheral devices to the on-board connectors. 4.5.1 SATA Drive Connection The KINO-EHL-J6412 is shipped with one SATA drive cable. To connect the SATA drive to the connector, please follow the steps below.

  • Page 75: Usb Cable Connection

    KINO-EHL-J6412 Mini-ITX SBC Figure 4-10: SATA Drive Cable Connection Step 8: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See Figure 4-10. Step 9: To remove the SATA cable from the SATA connector, press the clip on the connector at the end of the cable.

  • Page 76: Driver Download

    KINO-EHL-J6412 Mini-ITX SBC Step 11: Align the connectors. The cable has two connectors. Correctly align pin 1on each cable connector with pin 1 on the KINO-EHL-J6412 USB connector. Step 12: Insert the cable connectors. Once the cable connectors are properly aligned with the USB connectors on the KINO-EHL-J6412, connect the cable connectors to the on-board connectors.
  • Page 77 KINO-EHL-J6412 Mini-ITX SBC Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result. Step 3: Click the driver file name on the page and you will be prompted with the  following window.
  • Page 78 KINO-EHL-J6412 Mini-ITX SBC NOTE: To install software from the downloaded ISO image file in Windows 8, 8.1 or 10, double-click the ISO file to mount it as a virtual drive to view its content. On Windows 7 system, an additional tool (such as Virtual CD-ROM Control Panel from Microsoft) is needed to mount the file.

  • Page 79: Bios

    KINO-EHL-J6412 Mini-ITX SBC Chapter BIOS Page 65...

  • Page 80: Introduction

    KINO-EHL-J6412 Mini-ITX SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 81: Using Setup

    KINO-EHL-J6412 Mini-ITX SBC 5.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen. 5.1.2.1 Keyboard Navigation For keyboard navigation, use the navigation keys shown in Table 5-1. Function Up arrow Move to previous item Down arrow Move to next item Left arrow...

  • Page 82: Touch Navigation

    KINO-EHL-J6412 Mini-ITX SBC 5.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Button Function Previous Values Load the last value you set. Optimized Defaults Load the factory default values in order to achieve the best performance. Back Return to the previous menu.

  • Page 83: Getting Help

    KINO-EHL-J6412 Mini-ITX SBC 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window, press the key. 5.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration is made, CMOS defaults.

  • Page 84: Main

    KINO-EHL-J6412 Mini-ITX SBC 5.2 Main The Main BIOS menu (BIOS Menu 1 & BIOS Menu 2) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main (1/2) BIOS Menu 2: Main (2/2) Page 70...
  • Page 85 KINO-EHL-J6412 Mini-ITX SBC  BIOS Information The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information cannot be changed. The items shown in the system overview include:  BIOS Vendor: Installed BIOS vendor  Core Version: Current BIOS version ...
  • Page 86 KINO-EHL-J6412 Mini-ITX SBC The System Overview field also has two user configurable fields:  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, mont h and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 87: Advanced

    KINO-EHL-J6412 Mini-ITX SBC 5.3 Advanced Use the Advanced menu (BIOS Menu 3 ) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 88: Cpu Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 4 & BIOS Menu 5 & BIOS Menu 6) to view detailed CPU specifications or enable the Intel Virtualization Technology. BIOS Menu 4: CPU Configuration (1/3) Page 74...
  • Page 89 KINO-EHL-J6412 Mini-ITX SBC BIOS Menu 5: CPU Configuration (2/3) BIOS Menu 6: CPU Configuration (3/3) Page 75...
  • Page 90 KINO-EHL-J6412 Mini-ITX SBC  Intel (VMX) Virtualization Technology [Enabled] Use the Intel (VMX) Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time. ...
  • Page 91 KINO-EHL-J6412 Mini-ITX SBC  Tcc Activation Offset Use the Tcc Activation option to set Tcc activation temprature at which the Thermal Control Circuit must be activated.Tcc will be activated at: Tcc Activation Temp-Tcc Activation Offset. Tcc Activation Offset range is 0 to 63. ...

  • Page 92: Trusted Computing

    KINO-EHL-J6412 Mini-ITX SBC 5.3.2 Trusted Computing Use the Trusted Computing menu (BIOS Menu 7) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS Menu 7: PCH-FW Configuration  TPM Support [Enable] Use the TPM Support option to configure support for the TPM. ...

  • Page 93: Rtc Wake Settings

    KINO-EHL-J6412 Mini-ITX SBC 5.3.3 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 8) configures RTC wake event. BIOS Menu 8: RTC Wake Settings  Wake system with Fixed Time [Disabled] Use the Wake system with Fixed Time option to enable or disable the system wake on alarm event.

  • Page 94: F81966 Super Io Configuration

    KINO-EHL-J6412 Mini-ITX SBC Wake up hour Wake up minute Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. 5.3.4 F81966 Super IO Configuration Use the F81966 Super IO Configuration menu (BIOS Menu 9) to set or change the configurations for the serial ports.

  • Page 95: Serial Port 1 Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.4.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 10) to configure the serial port 1. BIOS Menu 10: Serial Port 1 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 96: Serial Port 2 Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.4.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 11) to configure the serial port 2. BIOS Menu 11: Serial Port 2 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 97: Serial Port 3 Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.4.3 Serial Port 3 Configuration Use the Serial Port 3 Configuration menu (BIOS Menu 12) to configure the serial port 3. BIOS Menu 12: Serial Port 3 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 98: Serial Port 4 Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.4.4 Serial Port 4 Configuration Use the Serial Port 4 Configuration menu (BIOS Menu 13) to configure the serial port 4. BIOS Menu 13: Serial Port 4 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 99: Serial Port 5 Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.4.5 Serial Port 5 Configuration Use the Serial Port 5 Configuration menu (BIOS Menu 14) to configure the serial port 5. BIOS Menu 14: Serial Port 5 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 100: Serial Port 6 Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.4.6 Serial Port 6 Configuration Use the Serial Port 6 Configuration menu (BIOS Menu 15) to configure the serial port 6. BIOS Menu 15: Serial Port 6 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 101: Ene Kb9068 Monitor

    KINO-EHL-J6412 Mini-ITX SBC 5.3.5 ENE KB9068 Monitor The ENE KB9068 Monitor menu (BIOS Menu 16) contains the smart fan mode configuration submenu and shows the state of H/W real-time operating temperature, fan speeds and system voltages. BIOS Menu 16: ENE KB9068 Monitor ...

  • Page 102: Smart Fan Mode Configuration

    KINO-EHL-J6412 Mini-ITX SBC  Voltages: CPU_CORE1 +12V +5VSB +3.3VSB 5.3.5.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 17) to configure the CPU/system fan start/off temperature and control mode. BIOS Menu 17: Smart Fan Mode Configuration ...

  • Page 103: Serial Port Console Redirection

    KINO-EHL-J6412 Mini-ITX SBC  Manual Mode The fan spins at the speed set in Manual Mode settings. Manual Mode PWM  CPU_FAN1 will start work according to this fixed PWM.  SYS_FAN2 Smart Fan Control [Auto Mode] Use the SYS_FAN2 Smart Fan Control option to configure the System Smart Fan. ...
  • Page 104 KINO-EHL-J6412 Mini-ITX SBC maintain a system remotely by re-directing keyboard input and text output through the serial port. BIOS Menu 18: Serial Port Console Redirection (1/2) Page 90...

  • Page 105: Console Redirection Settings

    KINO-EHL-J6412 Mini-ITX SBC BIOS Menu 19: Serial Port Console Redirection (2/2)  Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function.  Disabled Disabled the console redirection function EFAULT  Enabled Enabled the console redirection function The Console Redirection Settings submenu will be available when the Console Redirection option is enabled.

  • Page 106: Bios Menu 20: Com Console Redirection Settings

    KINO-EHL-J6412 Mini-ITX SBC BIOS Menu 20: COM Console Redirection Settings  Terminal Type [ANSI] Use the Terminal Type option to specify the remote terminal type.  VT100 The target terminal type is VT100  VT100+ The target terminal type is VT100+ ...
  • Page 107 KINO-EHL-J6412 Mini-ITX SBC  19200 Sets the serial port transmission speed at 19200.  38400 Sets the serial port transmission speed at 38400.  57600 Sets the serial port transmission speed at 57600.  115200 Sets the serial port transmission speed at 115200. EFAULT ...

  • Page 108: Nvme Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.3.7 NVMe Configuration Use the NVMe Configuration (BIOS Menu 21) menu to display the NVMe controller and device information. BIOS Menu 21: NVMe Configuration Page 94...

  • Page 109: Chipset

    KINO-EHL-J6412 Mini-ITX SBC 5.4 Chipset Use the Chipset menu (BIOS Menu 22) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS Menu 22: Chipset Page 95...

  • Page 110: System Agent (Sa) Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 23) to configure the System Agent (SA) parameters. BIOS Menu 23: System Agent (SA) Configuration  VT-d [Enabled] Use the VT-d option to enable or disable the VT-d capability. ...

  • Page 111: Memory Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.4.1.1 Memory Configuration Use the Memory Configuration submenu (BIOS Menu 24) to view memory information. BIOS Menu 24: Memory Configuration Page 97...

  • Page 112: Graphics Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.4.1.2 Graphics Configuration Use the Graphics Configuration (BIOS Menu 25) menu to configure the video device connected to the system. BIOS Menu 25: Graphics Configuration  Primary Display [Auto] Use the Primary Display option to select the primary graphics controller the system uses. The following options are available: ...
  • Page 113 KINO-EHL-J6412 Mini-ITX SBC Graphics option should be set to Enabled and the above Primary Display option should be set to IGFX.  Auto Auto mode  Disabled Disables IGFX.  Enabled Default Enables IGFX.  DVMT Pre-Allocated [160M] Use the DVMT Pre-Allocated option to set the amount of system memory allocated to the integrated graphics processor when the system boots.
  • Page 114 KINO-EHL-J6412 Mini-ITX SBC  LCD Control  iDPM Slot Control[Auto Detect Module(EDP/LVDS/VGA)] Use the iDPM Slot Control option to select iDPM module or auto detect for iDPM LVDS/EDP/VGA Module.  Auto Detect Auto detect for iDPM LVDS/EDP/VGA Module. EFAULT Module(EDP /LVDS/VGA) ...

  • Page 115: Pch-Io Configuration

    KINO-EHL-J6412 Mini-ITX SBC  LVDS Backlight PWM mode[Invert]  Invert Select Invert LVDS Backlight. EFAULT  Normal Select normol LVDS Backlight. 5.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 26) to configure the PCH parameters. BIOS Menu 26: PCH-IO Configuration ...

  • Page 116: Table 5-3: Bios Options And Configured Usb Ports

    KINO-EHL-J6412 Mini-ITX SBC  Power Saving Function(EUP) [Disabled] Use the Power Saving Function(EUP) BIOS option to enable or disable the power saving function.  Disabled Power saving function is disabled. EFAULT  Enabled Power saving function is enabled. It will reduce power consumption when the system is off.

  • Page 117: Pci Express Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 27) to configure the PCI Express slots. BIOS Menu 27: PCI Express Configuration 5.4.2.1.1 PCIe Root Port Setting Use the PCIEX4_1, M2_B_KEY Slot, M2_A_KEY Slot, submenu (BIOS Menu 28) to configure the PCI Root Port Setting.

  • Page 118: Bios Menu 28: Pcie Slot Configuration Submenu

    KINO-EHL-J6412 Mini-ITX SBC BIOS Menu 28: PCIe Slot Configuration Submenu  PCIe Speed [Auto] Use the PCIe Speed option to specify the PCI Express port speed. Configuration options are listed below.  Auto Auto mode. EFAULT  Gen1 Configure PCIe Speed to Gen1. ...

  • Page 119: M2_B_Key Slot

    KINO-EHL-J6412 Mini-ITX SBC  Disabled Do not detect if a non-compliance PCI Express EFAULT device is connected to the PCI Express port.  Enabled Detect if a non-compliance PCI Express device is connected to the PCI Express port. 5.4.2.1.2 M2_B_KEY Slot ...

  • Page 120: M2_A_Key Slot

    KINO-EHL-J6412 Mini-ITX SBC  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to configure whether to detect if a non-compliance PCI Express device is connected to the PCI Express port.  Disabled Do not detect if a non-compliance PCI Express EFAULT device is connected to the PCI Express port.
  • Page 121 KINO-EHL-J6412 Mini-ITX SBC  Gen1 Configure PCIe Speed to Gen1.  Gen2 Configure PCIe Speed to Gen2.  Gen3 Configure PCIe Speed to Gen3.  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to configure whether to detect if a non-compliance PCI Express device is connected to the PCI Express port.

  • Page 122: Sata Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 29) to change and/or set the configuration of the SATA devices installed in the system. BIOS Menu 29: SATA Configuration SATA Controller(s) [Enabled]  Use the SATA Controller(s) option to configure the SATA controller(s). ...

  • Page 123: Usb Configuration

    KINO-EHL-J6412 Mini-ITX SBC  Intel RST Premium Configures SATA devices to the Intel RST Premium With With Intel Optane Intel Optane System Acceleration mode. System Acceleration  Hot Plug [Disabled] Use the Hot Plug option (for S_ATA1) to designate the correspondent port as hot-pluggable.

  • Page 124: Hd Audio Configuration

    KINO-EHL-J6412 Mini-ITX SBC 5.4.2.4 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 30) to configure the PCH Azalia settings. BIOS Menu 30: HD Audio Configuration  HD Audio [Auto] Use the HD Audio option to enable or disable the High Definition Audio controller. ...

  • Page 125: Security

    KINO-EHL-J6412 Mini-ITX SBC 5.5 Security Use the Security menu (BIOS Menu 31) to set system and user passwords. BIOS Menu 31: Security  Administrator Password Use the Administrator Password to set or change a administrator password.  User Password Use the User Password to set or change a user password. Page 111...

  • Page 126: Boot

    KINO-EHL-J6412 Mini-ITX SBC 5.6 Boot Use the Boot menu (BIOS Menu 32) to configure system boot options. BIOS Menu 32: Boot 5.6.1 Boot Configuration  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots. ...

  • Page 127: Boot Option Priorities

    KINO-EHL-J6412 Mini-ITX SBC  UEFI LAN PXE Boot [Disabled] Use the UEFI LAN PXE Boot option to enable or disable UEFI network stack.  Disabled Ignore all PXE Option ROMs EFAULT  Enabled Load PXE Option ROMs. 5.6.2 Boot Option Priorities Use the Boot Option # N to choose the system boots from the peripherals you selected The following Boot Options are listed as an example.

  • Page 128: Save & Exit

    KINO-EHL-J6412 Mini-ITX SBC 5.7 Save & Exit Use the Save & Exit menu (BIOS Menu 33) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS Menu 33: Save & Exit  Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.
  • Page 129 KINO-EHL-J6412 Mini-ITX SBC  Restore Defaults Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this operation.  Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. Restore User Defaults ...

  • Page 130: A Regulatory Compliance

    KINO-EHL-J6412 Mini-ITX SBC Appendix Regulatory Compliance Page 116...
  • Page 131 KINO-EHL-J6412 Mini-ITX SBC DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 132: B Product Disposal

    KINO-EHL-J6412 Mini-ITX SBC Appendix Product Disposal Page 118...
  • Page 133 KINO-EHL-J6412 Mini-ITX SBC CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 134: Cbios Options

    KINO-EHL-J6412 Mini-ITX SBC Appendix BIOS Options Page 120...
  • Page 135 KINO-EHL-J6412 Mini-ITX SBC Below is a list of BIOS configuration options in the BIOS chapter.  BIOS Information ......................71  Compute Die Information .................... 71  PCH Information ......................71  System Date [xx/xx/xx] ....................72  System Time [xx:xx:xx]....................72 ...
  • Page 136 KINO-EHL-J6412 Mini-ITX SBC  SYS_FAN2 Start Temperature ..................89  SYS_FAN2 Off Temperature ..................89  SYS_FAN2 Start PWM ....................89  Console Redirection [Disabled] .................. 91  Terminal Type [ANSI] ....................92  Bits per second [115200] .................... 92 ...
  • Page 137 KINO-EHL-J6412 Mini-ITX SBC  Boot Option #1 ......................113  Boot Option #2 ......................113  Save Changes and Reset ..................114  Discard Changes and Reset ..................114  Restore Defaults ....................... 115  Save as User Defaults ....................115 ...

  • Page 138: D Watchdog Timer

    KINO-EHL-J6412 Mini-ITX SBC Appendix Watchdog Timer Page 124...
  • Page 139 KINO-EHL-J6412 Mini-ITX SBC NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 140 KINO-EHL-J6412 Mini-ITX SBC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 141: E Error Beep Code

    KINO-EHL-J6412 Mini-ITX SBC Appendix Error Beep Code Page 127...

  • Page 142: Pei Beep Codes

    KINO-EHL-J6412 Mini-ITX SBC E.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available E.2 DXE Beep Codes...

  • Page 143: F Hazardous Materials Disclosure

    KINO-EHL-J6412 Mini-ITX SBC Appendix Hazardous Materials Disclosure Page 129...

  • Page 144: Rohs Ii Directive (2015/863/Eu)

    KINO-EHL-J6412 Mini-ITX SBC F.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 145: China Rohs

    KINO-EHL-J6412 Mini-ITX SBC F.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 131...

This manual is also suitable for:

Kino-ehl-j6412

Table of Contents
