INSTALLATION
Installation
6.1

Cold water connection to tap

f Seal the thread of the tap body using hemp or Teflon tape.
f Screw the tap extension together with flat gasket to the tap
body.
f Slide the wall bezel over the tap extension.
f Seal the thread of the tap extension using hemp or Teflon
tape.
f Fit the tap body together with wall bezel and tap extension
to the cold water pipe. Align the tap body horizontally when
doing so.
www.stiebel-eltron.com
6.2 Cold water connection to instantaneous water
heater (not for DCE compact instantaneous
water heaters)
1 Anchor pin
f Secure the anchor pin and wall bezel to the wall.
f Seal the thread of the tap body using hemp or Teflon tape.
f Screw the tap extension together with flat gasket to the tap
body.
f Fit the tap body with the flat seal ring to the anchor pin.
Align the tap body horizontally when doing so.
1
MEKD | MEBD | 21
