Sim Card; Power - Advantech UCR11 v2 Start Manual

2. SIM Card

The SIM card reader for one or two Mini SIM cards (2FF with size of 25.0 x 15.0 x 0.76 mm)
is located on the router's front panel. The full version of the router contains two readers. If you
intend to use this device to communicate over a cellular network, please place an activated
data-provisioned SIM card into the SIM card reader. Insert your SIM card into the SIM1 or
SIM2 holder and push it to the reader, see the figure below. You can install two SIM cards
simultaneously to utilize the SIM card switching feature.
Disconnect the router from the power supply before handling the SIM card!

3. Power

The router requires an external DC power supply. The DC voltage required is between
+10 and +30 V DC. The router has built-in protection against reverse polarity without signaling.
Connect the power supply cable to the PWR connector on the router's front panel (see the
figure below) and tighten the locking screws.
