Directechs DIRECTED DIRECTWIRE DB3 Installing Manual page 10

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
10 403.TL6 2.26 2016 Toyota Corolla (Smart Key)
©2023 Directed. All rights
Description
No Connection
No Connection
No Connection
No Connection
No Connection
[1]
(-) Hood Switch Input
No Connection
No Connection
No Connection
No Connection
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color
Description
Description
