- Page 1 ASSEMBLY INSTRUCTIONS Description : SUPER KITCHEN ISLAND Item No. : WC-4824 ITEM NO.: WC-4824 Printed in Vietnam REVISED NOV 14, 2014 - 1 -...
-
Page 2: Before Assembly
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch (L-R) Shelf ITEM NO.: WC-4824 Printed in Vietnam REVISED NOV 14, 2014 - 2 -... -
Page 3: Hardware List
Cup holder Allen key Short screw (4x80mm) (M3x15mm) STEP 1 Attach cup holders (4) to top (A) with screws (7) as shown below. Tighten with a screwdriver. ITEM NO.: WC-4824 Printed in Vietnam REVISED NOV 14, 2014 - 3 -... - Page 4 STEP 3 Insert pins (9) into legs (B). Place the shelves (C) on the pins (9) and attach with screws (10) as shown below. Tighten with a screwdriver. ITEM NO.: WC-4824 Printed in Vietnam REVISED NOV 14, 2014 - 4 -...
- Page 5 STEP 4 Attach knob (8) to front of drawers with Pan head screw (6) as shown below. Tighten with a screwdriver. ITEM NO.: WC-4824 Printed in Vietnam REVISED NOV 14, 2014 - 5 -...
