- Page 1 ASSEMBLY INSTRUCTIONS Description : 10 IN TURNED PEDESTAL Item No. : T-54B AND T-60RT OR T-48RT OR T-52T (PACKED IN SEPARATE BOX) ITEM NO: T-54B AND T-60RT OR T-48RT OR T-52T Printed in Vietnam (PACKED IN SEPARATE BOX) REVISED DEC 03, 2014 - 1 -...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is missing or defective, please contact the store where purchased.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following parts: Description Sketch Description Sketch Flat washer Lock washer (8.5x19mm) (8.5x13mm) Hexagon nut Wrench (M8x13mm) (13mm) Allen key...
- Page 4 STEP 2 Use the Allen key (5) to loosen the bolts and washers, and take off the plate underneath the table top. STEP 3 Place the plate on top of the pedestal (B), attach with washers (6) and (2), and nuts (3) as shown below.
- Page 5 STEP 4 Carefully put the pedestal block on the bottom side of the table top, attach the top to plate with bolts and washers (from step 2) and tighten with the Allen key (5) ITEM NO: T-54B AND T-60RT OR T-48RT OR T-52T Printed in Vietnam (PACKED IN SEPARATE BOX) REVISED DEC 03, 2014...
