- Page 1 ASSEMBLY INSTRUCTIONS Description : VISTA ROUND COFFEE TABLE Item No. : OT-15CR ITEM NO.: OT-15CR Printed in Vietnam ISSUED MAY 28, 2019 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the table with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: OT-15CR Printed in Vietnam ISSUED MAY 28, 2019 - 2 -... -
Page 3: Part List
Sketch Description Sketch Bolt Screw (M8 x 60mm) (3.5 x 15mm) Lock Washer L-bracket (8.5 x13mm) Flat Washer Allen Key (8.5 x19mm) (M4 x 30mm x 110mm) ITEM NO.: OT-15CR Printed in Vietnam ISSUED MAY 28, 2019 - 3 -... - Page 4 STEP 1 Attach legs (B) to the top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (6). ITEM NO.: OT-15CR Printed in Vietnam ISSUED MAY 28, 2019 - 4 -...
- Page 5 STEP 2 Attach shelf (C) to legs (B) with brackets (5) and screws (4) as shown below Tighten with a screwdriver. ITEM NO.: OT-15CR Printed in Vietnam ISSUED MAY 28, 2019 - 5 -...
- Page 6 STEP 3 Adjust the levelers to the appropriate height to level the table. ITEM NO.: OT-15CR Printed in Vietnam ISSUED MAY 28, 2019 - 6 -...
