- Page 1 ASSEMBLY INSTRUCTIONS Description : GATHERING BUTTERFLY LEAF TABLE Item No. : T-4254XBT AND T-4254XBG Printed in Vietnam ITEM NO.: T-4254XBT AND T-4254XBG REVISED AUG 18, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 1 -...
- Page 2 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Printed in Vietnam ITEM NO.: T-4254XBT AND T-4254XBG REVISED AUG 18, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 2 -...
- Page 3 (M4x28mm) Long wood Short wood screw screw (M3.5x15mm) (M4x30mm) L-bracket (1x18x18mm) NOTE: HARDWARE IS PACKED IN CARTON T-4254XBG Printed in Vietnam ITEM NO.: T-4254XBT AND T-4254XBG REVISED AUG 18, 2015 THIS ITEM IS PACKED IN TWO CARTONS - 3 -...
- Page 4 Attach side panels (B) to bottom panel (D). Then attach them to legs (F) with bolts (1), washers (2) and (3). Tighten with Allen key (7). Printed in Vietnam ITEM NO.: T-4254XBT AND T-4254XBG REVISED AUG 18, 2015 THIS ITEM IS PACKED IN TWO CARTONS...
- Page 5 Carefully attach top (A) to the base (from Step 3) with nuts (4), washers (5) and (6). Tighten with the wrench (8). Printed in Vietnam ITEM NO.: T-4254XBT AND T-4254XBG REVISED AUG 18, 2015 THIS ITEM IS PACKED IN TWO CARTONS...
- Page 6 Place the leaves in the center of the open table top. Push the table top closed. Lock the mechanism underneath 2 sides of the table top as shown below.. Printed in Vietnam ITEM NO.: T-4254XBT AND T-4254XBG REVISED AUG 18, 2015 THIS ITEM IS PACKED IN TWO CARTONS...
