Summary of Contents for PR Lighting PR-8846
- Page 1 XRLED 3500-W Wash/Framing PR-8846 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
- Page 2 INDEX 1 SAFETYAND WARNINGS …………………………………………………………………………………………… 2 INSTRUCTIONS …………………………………………………………………………………………………… … 3 APPEARANCE …………………………………………………………………………………………………… …… 4 INSTALLATION …………………………………………………………………………………………………… …… 5 SETUPAND CONFIGURATION ……………………………………………………………………………………… 6 OPERATION MENU …………………………………………………………………………………………………… 7 DMX PROTOCOL ……………………………………………………………………………………………………… 8 SIGNS ON THE TOUCH SCREEN …………………………………………………………………………………… 9 ERROR MESSAGES …………………………………………………………………………………………………… TECHNICAL DATA ……………………………………………………………………………………………………...
-
Page 3: Safety And Warnings
Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty. - Page 4 Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned.. ● Do not connect this device to any type of dimmer pack. ● If the lamp, lens and screen protective cover of the a lighting fixture have obvious damage, i.e., to the extent that ●...
- Page 5 If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the projector has over-temperature protective device. If the temperature is too high, the protective device will be triggered to shut the projector off.
- Page 6 HEAD BASE 4. INSTALLATION RIGGING ● During transportation, please lock the projector well; Before the use of projector please unlock the head. It’s forbidden to run the projector without unlock Pan and Tilt CLAMP SAFETY WARMING CORD Please run safety cord through the safety hole circled in the diagram for safety Note:...
- Page 7 Take 2 clamps and 2 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
- Page 8 wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets. The XLR's are connected as shown in the figure above. Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other.
-
Page 9: Dmx Startaddress
To view or change its setup, touch any white area of the screen or push the key OK for more than 3 seconds to unlock the display(While ► key t o enter into function menus. Each main menu has its submenus and only on battery, push OK key). - Page 10 be set accordingly. After Powered on, the group will run in Master/Slave Mode FIRMWARE UPGRADE VIAUSB PORT After the .PRS files for upgrade copied to the U flash drive and then it plugged into USB port, the name of the file or its folder will be seen under the menu of Service/USB Firmware Upgrade .
-
Page 11: Operation Menu
BRIGHTNESS CALIBRATION ● For brightness calibration function, a controller can be used on the projectors in a DMX chain or a projector be done individually. After running for some time, the projectors need to be recalibrated in brightness for conformity with the help of LED brightness calibration channel via controller. - Page 12 Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Config Display Invert Invert ON InvertAuto English Language Setting Chinese Touch Calibration 0-999 Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm/Cancel Factory Defaults Restore Defaults? Confirm/Cancel Pan DMX Invert OFF/ ON Tilt DMX Invert...
- Page 13 Led Sensor XX℃/F Sys= XXX Display Board Boot =XXX Sys= XXX Pan and Tilt Board Boot =XXX Sys= XXX Driver Board 1 Boot =XXX Sys= XXX Software Version Driver Board 2 Boot =XXX Sys= XXX Driver Board 3 Boot =XXX Sys= XXX Blade Board Boot =XXX...
-
Page 14: Dmx Protocol
DMX PROTOCOL Short Standard Extended Decimal Function Description Decimal High mode mode mode Strobe Close Pulse strobe speed from slow to fast Strobe speed slow to fast Dimmer Close Non-linear dimmer from dark to bright (0-100%) Dimmer Fine Dimmer in 16 bit CYM Macro The following functions will disable CMY ,CTO No Function... - Page 15 Colour Macro 20 Colour Macro 21 Colour Macro 22 Colour Macro 23 LEE 004 (Medium Bastard Amber) LEE 010 (Medium Yellow) LEE 019 (Fire) LEE 026 (Bright Red) LEE 058 (Lavender) LEE 068 (Sky Blue) LEE 071 (Tokyo Blue) LEE 079 (Just Blue) LEE 088 (Lime Green) LEE 090 (Dark Yellow Green) LEE 100 (Spring Yellow)
- Page 16 LEE 157 (Pink) LEE 158 (Deep Orange) LEE 162 (Bastard Amber) LEE 164 (Flame Red) LEE 165 (Daylight Blue) LEE 169 (Lilac Tint) LEE 170 (Deep Lavender) LEE 172 (Lagoon Blue) LEE 179 (Chrome Orange) LEE 180 (Dark Lavender) LEE 181 (Congo Blue) LEE 197 (Alice Blue) LEE 201 (Full C.T.
- Page 17 CTO in 16 Bit precision Colour Wheel 1 Continual positioning index 0-360° positioning Open Open/Color1(Red) Color1(Red) Color1(Red)/Color 2(Green) Color 2(Green) Color 2(Green)/Color 3(Blue) Color 3(Blue) Color 3(Blue)/ Color 4(Orange) Color 4(Orange) Color 4(Orange) /Color 5(Pink) Color 5(Pink) Light cyan ） Color 5（Pink）/Color 6（...
- Page 18 Clockwise rainbow effect rotation speed from slow to fast Anti-clockwise rainbow effect rotation speed from slow to fast Color Wheel 2 Fine Color Continual positioning in 16 Bit precision Framing blade 1 left Framing blade 1 left linearly closing from big to small Framing blade 1 left in 16 bit Framing blade 1 left fine adjustment Framing blade 1 right...
- Page 19 Framing module fine rotation Focus Linearly focusing Focus Fine Focus in 16 precision Zoom Linearly zooming Zoom Fine Zoom in 16 Bit precision Pan movement Pan Fine Pan movement in 16 bit precision Tilt Tilt movement Tilt fine Tilt movement 16 bit precision Pan/Tilt speed Fast Speed Mode Pan &Tilt speed from fast to slow...
- Page 20 LED refresh rate 2400Hz LED refresh rate 4800Hz LED refresh rate 10000Hz LED refresh rate 12000Hz LED refresh rate 1500Hz LED refresh rate 20000Hz LED refresh rate 25000Hz Reserved Pan/Tilt speed mode Pan/Tilt time mode Reserved Reserved Pan/Tilt reset Colour system reset Gobo wheels reset Reserved Zoom/focus reset...
-
Page 21: Error Messages
Step2:DMX value range for Channel LED brightness calibration confirmation is between 0 and 200. If the fader is moved between 201 and 209 and stays there for more than 5s, the desired brightness value will be stored into fixtures. Step 3:Move the faders for DMX channels LED brightness calibration and LED brightness calibration confirmation respectively to zero. -
Page 22: Technical Data
Fan board Error Check signal wire Lamp Off[Fan Error Check if all fans are normal Error] Time IC Error Contact the manufacturer 10. TECHNICALDATA ELECTRICALPARAMETERS Input Voltage: 100V-240VAC，50/60Hz Input Power: 1900W@220V Power factor: PF>0.95 9.0A @ 220V Current at maximum: OPTICALSYSTEM L ight sources : 1500W white LED module... -
Page 23: Beam Angle
1 Framing module: 4 framing blades to make graphics with different sizes and shapes Framing module rotates bi-directionally up to 360 °and continually, each framing blade produces full curtain effect BEAM ANGLE 1/2θ（peak）:7°～ 40°, with 16 bit precision 1/10θ（peak）:12°～ 60°, with 16 bit precision FOCUS DMX linear focus DIMMER... -
Page 24: Operation Temperature
OTHER FUNCTIONS Pan and Tilt speeds adjustable Pan and Tilt swappable and invertible High precision magnet sensor for positioning 3.2-inch touch color screen, Chinese and English menus, Screen automatic lock –up while standby Error diagnostic system with sensors Smart fan cooling system Display of fixture hours and software versions Modular construction for easy maintenance Isolated input signals... -
Page 25: Light Output
LIGHT OUTPUT Beam angle: File angle:... -
Page 26: Circuit Diagram
11. CIRCUIT DIAGRAM... -
Page 28: Component Order Codes
COMPONENT ORDER CODES NAME CODE NUMBER REMARK 192010228A SWITCHING POWER SUPPLY 192010215B SWITCHING POWER SUPPLY LED LIGHT SOURCES (HIGH 150020334 CRI) 270041098 FUSE IN CERAMIC TUBE 030040262 PAN MOTOR 030040262 TILT MOTOR 030040219A COLOR WHEEL MOTOR 030040210A CMY MOTOR 030040211A 030040291 FOCUS MOTOR 030040261A... - Page 29 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320021555...
