Summary of Contents for PR Lighting PR-8835
- Page 1 XRLED 3000-W Wash PR-8835 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
- Page 2 Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
-
Page 3: Safety And Warnings
1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Goggles User Electrical Protective High Warning Flames Manual shock Gloves Temperature When unpacking, check if there is transportation damage before using the projector. - Page 4 While being operated, the projector should not be under rains or in humidity. ● Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . There are safety cord holes at the bottom of the base of a projector.
- Page 5 Do not use alcohol or other organic solvent to clean the housing to avoid damage. ● Do not use any solvent with chemical elements to clean color filters or hot mirror. ● LUBRICATION ● To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and focus lens be lubricated every 2 months.
- Page 6 SAFETY WARMING CLAMP CORD Please run safety cord through the safety hole circled in the diagram for safety Note: 1. the distance between the foot of the base and the front lens cover(the head facing downward) 2. the distance between mounting truss and the front lens cover( the head facing downward) 3.
- Page 7 projector be connected with power separately so that they may be individually switched on and off. The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in ● accordance with the standards concerned. If any questions about the electrical installation, do not continue but consult a qualified electrician. ●...
- Page 8 DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 SETUPAND CONFIGURATION FRONT PANELOPERATION ● The configuration and start address can be set conveniently via push button and color touch screen.
- Page 9 Select DMX control Mode---- Wireless First (Note: Do not select XLR ONLY). The DMX wireless control function is activated. Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press “Enter”...
-
Page 10: Operation Menu
FAN SPEED MODES ● It has standard and theater modes. Theater mode is quiet mode. Its setups are as follows: ► button to enter into the menus and select 1. Hold the OK button for more than 3s to unlock the control panel and then push “Option Settings”. - Page 11 Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Config Display Invert Invert ON InvertAuto English Language Setting Chinese Touch Calibration 0-999 Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm/Cancel Factory Defaults Restore Defaults? Confirm/Cancel Pan DMX Invert OFF/ ON Tilt DMX Invert...
-
Page 12: Dmx Protocol
Sys= XXX Fan Board Boot =XXX Electronic SN= Electronic SN ************ XRLED 3000- W Wash RDM Device Label ANSI E1.20 RDM Speed Status Base Fan 1 XXX Base Fan 2 XXX Color Wheel Fan XXX XXX Head Fan1 Head Fan2 Fan Status LED Fan 1 LED Fan 2... - Page 13 The following functions will disable CMY ,CTO No Function Colour Temperature 2700K Colour Temperature 3000K Colour Temperature 3500K Colour Temperature 4000K Colour Temperature 4500K Colour Temperature 5000K Colour Temperature 5700K Colour Macro 1 Colour Macro 2 Colour Macro 3 Colour Macro 4 Colour Macro 5 Colour Macro 6 Colour Macro 7...
- Page 14 LEE 101 (Yellow) LEE 102 (Light Amber) LEE 103 (Straw) Lee 104 (Deep Amber) LEE 105 (Orange) LEE 106 (Primary Red) LEE 111 (Dark Pink ） LEE 115 (Peacock Blue) LEE 116 (Medium Blue-Green) LEE 117 (Steel Blue) LEE 118 (Light Blue) LEE 119(Deep Blue) LEE 120 (Dark Blue) LEE 121 (LEE Green)
- Page 15 LEE 204 (Full C.T. Orange) LEE 205 (Half C.T. Orange) LEE 206 (Quarter C.T. Orange) LEE 247 (LEE Minus Green) LEE 248 (Half Minus Green) LEE 281 (Three Quarter C.T. Blue) LEE 285 (Three Quarter C.T. Orange) LEE 352 (Glacier Blue) LEE 353 (Lighter Blue) LEE 715 (Cabana Blue) LEE 778 (Millennium Gold)
- Page 16 Color 5(Pink) Light cyan ） Color 5（Pink）/Color 6（ Light cyan ) Color 6( Light cyan )/ Open Color6( Open Clockwise rainbow effect rotation speed from slow to fast Anti-clockwise rainbow effect rotation speed from slow to fast Color Wheel 1 Fine Color Continual positioning in 16 Bit precision Colour Wheel 2 Continual positioning...
- Page 17 Pan movement in 16 bit precision Tilt Tilt movement Tilt fine Tilt movement 16 bit precision Pan/Tilt speed Fast Speed Mode Pan &Tilt speed from fast to slow CRI MODE Normal mode High CRI mode Power/Special functions No function: Reserved To activate following functions, stay in DMX value for at least 5 s Graphic display On Graphic display Off...
- Page 18 Pan/Tilt reset Colour system reset Gobo wheels reset Reserved Zoom/focus reset Others reset Total reset Reserved Reserved LED brightness calibration LED brightness 50%-100%, linear calibration LED brightness calibration confirmation Ready to store calibrated value Store calibrated value in the fixture(stay in the DMX range for more than 5s) Reserved Reserved...
-
Page 19: Error Messages
8. SIGNS OF THE TOUCH SCREEN Config Settings Option Settings Information Address Error Messages Service Operation Mode Reset User Memories 9.ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type Correction... -
Page 20: Optical System
10. TECHNICALDATA ELECTRICALPARAMETERS Input voltage: 100V-240VAC，50/60Hz Input power: 1500W @ 220V Power factor: PF>0.95 7.1A @ 220V Current at maximum: OPTICALSYSTEM Light sources : 1200W white LED module 6900K Colour Temperature : CRI: Ra≥95、R9≥95 ≥20000hrs Manufacturers Rated Lamp Life : COLOR S CMY linear coloring mixing system with macros 2 Color Wheels：... -
Page 21: Head Movement
DIMMER Linear electronic dimmer 0-100% with 16 bit control 3 dimmer speeds 4 dimmer gamma curves Dimmer frequency(1.2K-25K) adjustable, suitable for 4K high speed video camera STROBE Electronic strobe, 0.3~25 F.P.S, optional synchronized or non-synchronized strobe HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction and 16 bit control ADVANCED MACROS Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K Standard color macros: 89 color options based on standard color chart. -
Page 22: Operation Temperature
Isolated input signals Firmware update via DMX cable IP RATING IP20 OPERATION TEMPERATURE °C Ambient temperature at maximum：45 WEIGHT Net weight 40.2 KG SIZES （mm） ： BASE INSTALLATION （mm） ：... -
Page 23: Light Output
LIGHT OUTPUT 11. CIRCUIT DIAGRAM... -
Page 25: Component Order Codes
COMPONENT ORDER CODES NAME CODE NUMBER REMARK 192010228A SWITCHING POWER SUPPLY 192010215B SWITCHING POWER SUPPLY 150020326 LED LIGHT SOURCES 270041098 FUSE IN CERAMIC TUBE 030040262 PAN MOTOR 030040262 TILT MOTOR 030040220A COLOR WHEEL MOTOR 030040210A CMY MOTOR 030040211A 030040291 FOCUS MOTOR 030040261A ZOOM MOTOR 030060104... - Page 26 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320021568...
