Item
Matte Gen
Matte Format
Matte Color
Audio Bypass
Sub-Image ID
Clean Switch
Status
(read-only)
Clean Switch
Clean Switch
Mode
Clean Switch
Delay
Trigger
ULTRIX-MODX-IO User Guide (v1.0)
Table 3 Port Configuration — Views > Ports
Parameters
Disable
Static
Bouncing Box
Luma Sequence
#
#
Selected
Cleared
3G
2SI
Locked
Not Locked
Selected
Cleared
Reference
Input
#
#
Description
Disable an internally generated test pattern. This is
the default.
Generates a static color matte
Generates a static color matte with a
complimentary colored moving box
Generates a luminance shifting sequence based on
chosen color
Specifies the signal format of the generated test
pattern. If you select Auto, the test pattern
automatically matches the incoming signal type.
Specifies the color of the test signal
When Audio Bypass is enabled for an input, the
audio will follow the SDI regardless of any individual
audio channel routing or configuration on the
output.
The individual channels of an input in Bypass mode
are still de-multiplexed and available for audio
routing via the audio matrix.
Disables this feature
Some legacy equipment does not accept a 2SI
SMPTE-352 payload identifier for quad-link SDI. You
may need to select this if you are connecting legacy
equipment to the specified output on the
ULTRIX-MODX-IO.
Set the SMPTE-352 payload identifier to 2SI for
quad-link.
The specified output is locked to its input.
The specified output is not locked to its input.
Clean Switch is applied to the specified output. The
Clean Switch Delay value is applied.
Clean Switch is not applied to the specified output.
Clean Switch is based on the reference signal
available on the REF port of the router
Clean Switch is based on the input signal available
on the specified port of the router
Specifies the Clean Switch buffer depth. Select
between 1/16 to full line to clean switch between
signals with slight timing offsets.
Specifies which reference signal trigger to use. Refer
to the user guide for your router.
Configuration • 39
