2. Locate the markings on the SFP module that identify the orientation for installing. These
markings may include Tx/Rx icons, or arrows that indicate the signal flow direction.
Caution
— Do not install an SFP module with fiber-optic cables attached. Doing so can damage the
cables, the cable connector, the SFP module or all three.
3. Align the SFP module in front of the empty port.
4. Insert the SFP module into the port, ensuring it is seated home and the latch is engaged.
Caution
— Do not remove the dust caps from a SFP module until you are ready to connect the cables.
